- Page 1 Latest generation testo air velocity & IAQ probes with Bluetooth handle ® Instruction manual 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Safety And Disposal
Only carry out maintenance and repair work on this instrument which is described in the documentation. Follow the prescribed steps exactly when doing the work. Use only original spare parts from Testo. • Temperature information given on probes/sensors relates only to the measuring range of the sensor technology. -
Page 3: System Description
The graphic below shows what options the system offers. You will find detailed information about how each of the probes works along with the testo 440 measuring instrument in the corresponding chapter of the instruction manual for the measuring instrument. - Page 4 ® handle for humidity and temperature sensor connecting testo 440 probe (order no. 0632 1550) heads (order no. 0554 1111) 3 High-precision 4 Temperature/humidity probe temperature/humidity probe head (order no. 0636 9730) head (order no. 0636 9770)
-
Page 5: Description Of The Instrument
440 probe heads (0554 1111) Application The handle with Bluetooth 0554 1111 is used for the wireless connection of ® probe heads to the testo 440 measuring instrument. Observe the information on the measuring process in the detailed instrument instruction manual. - Page 6 3.2 Hot wire probe with Bluetooth ® including temperature and humidity sensor (0635 1571) In conjunction with the testo 440, the hot wire probe is suitable for flow and humidity measurements in ventilation ducts. Structure 1 Probe head 2 Probe head connection...
- Page 7 3 Description of the instrument Low flow velocities may result in greater measurement uncertainties during temperature and humidity measurement. The probe should be switched on outside a duct under the following conditions: Ambient temperature: 20°C Flow: approx. 0 m/s. Connect hot wire probe to the handle Turn quick-release connector, viewed from the handle end, through 90°...
- Page 8 3.3 Vane probe (Ø 16 mm) with Bluetooth ® including temperature sensor (0635 9571) Application In conjunction with the testo 440, the vane probe (Ø 16 mm) is suitable for flow measurements in ventilation ducts. Structure 1 Probe head 2 Probe head connection...
- Page 9 Bluetooth , including temperature ® sensor (0635 9371) Application In conjunction with the testo 440, the high-precision vane probe (Ø 100 mm) is used for flow measurement, e.g. at ventilation outlets. Structure 1 Probe head 2 Handle adapter 3 Quick-release connector for...
- Page 10 3 Description of the instrument CAUTION Damage to sensor possible! - Do not touch sensor! The testovent bracket included in the package is intended for the testovent 417 measurement funnel. Connect high-precision vane probe (Ø 100 mm) to the handle Turn quick-release connector, viewed from the handle end, through 90°...
- Page 11 3.5 Vane probe (Ø 100 mm) with Bluetooth ® including temperature sensor (0635 9431) Application In conjunction with the testo 440, the vane probe (Ø 100 mm) is used for flow measurement, e.g. at ventilation outlets. Structure 1 Probe head 2 Handle adapter...
- Page 12 3.6 High-precision temperature/humidity probe with Bluetooth (0636 9771) ® Application In conjunction with the testo 440, the high-precision temperature/humidity probe is used to measure humidity and temperature. Structure 1 Probe head 2 Quick-release connector 3 LED status display...
- Page 13 The high-precision temperature/humidity probe is ready to use. 3.7 Temperature/humidity probe with Bluetooth (0636 9731) ® Application In conjunction with the testo 440, the temperature/humidity probe is used to measure humidity and temperature. Structure 1 Probe head 2 Quick-release connector for probe heads and adapter...
- Page 14 Bluetooth , including ® temperature and humidity sensor (0632 1551) Application In conjunction with the testo 440, the CO probe is used to determine CO to measure humidity and temperature. Structure 1 Probe head 2 Quick-release connector for...
- Page 15 3 Description of the instrument CAUTION • The probe contains sensitive visual components. Please handle the probe with care. • Strong vibrations alter the factory calibration. Checking of readings in fresh air 350 to 450 ppm CO2 (urban air up to 700 ppm CO2). •...
- Page 16 3 Description of the instrument 3.9 CO probe with Bluetooth ® (0632 1271) Application In conjunction with the testo 440, the CO probe is used to determine the CO concentration in the environment. Structure 1 Probe head 2 Quick-release connector for...
- Page 17 4 Commissioning 4 Commissioning Switching on - Press button on the handle. The handle is switched on. Switching off - Press and hold the button on the handle for three seconds. The handle is switched off. LED status display LED status display Meaning Flashing red...
-
Page 18: Maintenance
5 Maintenance 5 Maintenance Replacing the batteries Open the battery compartment: push lock down and remove cover. Take spent batteries out of the battery compartment and replace with new batteries (4 x AA type). Pay attention to polarity. Put battery cover on and push lock back up. -
Page 19: Questions And Answers
Recalibration of the probes once every 12 months is recommended in many applications. This can be carried out by Testo Industrial Services (TIS) or other certified service providers with the aid of easy-to-use service software. 6 Questions and answers... -
Page 20: Technical Data
For continuous use in high-humidity ranges > 80% RH at ≤ 30°C for > 12 h > 60% RH at > 30°C for > 12 h please get in touch with Testo Service or contact us via the Testo website. Bluetooth handle for connecting testo 440 probe heads (0554 1111) ®... - Page 21 7 Technical data Feature Value Accuracy ±3.0% RH (10 to 35% RH) (at 25°C, ±1 digit) ±2.0% RH (35 to 65% RH) ±3.0% RH (65 to 90% RH) ±5% RH (remaining measuring range) Additional uncertainty: - Hysteresis: ±1.0% RH - Long-term stability: ±1% RH / year Resolution 0.01 m/s 0.1°C...
- Page 22 7 Technical data Feature Value Bluetooth range 20 m (free field) © Battery life 70 h Dimensions 790 mm x 50 mm x 40 mm Probe head length 230 mm Ø probe head 16 mm Dimensions of probe head Extension length: 1000 mm with telescope Probe length from handle end to probe head end with retracted telescope:...
- Page 23 7 Technical data Vane probe (Ø 100 mm) with Bluetooth ® , including temperature sensor (0635 9431) Feature Value Measuring range 0.3 to 35 m/s -20 to 70°C Accuracy ±(0.1 m/s + 1.5% of m.v.) (0.3 to 20 m/s) (at 22°C, ±1 digit) ±(0.2 m/s + 1.5% of m.v.) (20.01 to 35 m/s) ±0.5°C ±0.5°C (-20 to 0°C)
- Page 24 7 Technical data Feature Value Battery life 140 h Dimensions 295 mm x 50 mm x 40 mm Probe head length 140 mm Ø probe head Ø 12 mm Directives, standards and EU directive: 2014/30/EU tests Temperature/humidity probe with Bluetooth ®...
- Page 25 7 Technical data CO2 probe with Bluetooth ® , including temperature and humidity sensor (0632 1551) Feature Value Measuring range 0 to +50°C 5 to 95% RH 0 to 10,000 ppm CO2 700 to 1100 hPa Accuracy ±0.5°C (at 22°C, ±1 digit) ±(50 ppm + 3% of m.v.) (0 to 5,000 ppm) ±(100 ppm + 5% of m.v.) (5,001 to 10,000 ppm)
- Page 26 7 Technical data CO probe with Bluetooth ® (0632 1271) Feature Value Measuring range 0 to 500 ppm Accuracy ±3 ppm (0 to 30 ppm) (at 22°C, ±1 digit) ±10% of m.v. (30.1 to 500 ppm) Resolution 0.1 ppm Storage temperature -20 to +50°C / recommended: -10 to +30°C Operating temperature -5 to +50°C...
-
Page 27: Accessories And Spare Parts
90° angle Telescope extension (length 0.40 to 0.85 m) for testo 0554 0990 440 flow probes 90° angle for connecting the testo 440 vane probe (Ø 0554 0991 100 mm) Combi-case for testo 440 and multiple probes 0516 4401 1.800.561.8187... -
Page 28: Authorisations And Certification
The user and every owner has the obligation to adhere to these regulations and prerequisites for use and acknowledges that the re-sale, export, import, etc., in particular in, to or from countries without wireless authorization, is their responsibility. Product 0554 1111 Mat.-No.: 0554 1111 Date 06.12.2017... - Page 29 9 Authorisations and certification Country Comments Product FCC ID: WAF-05541111 FCC Warnings Bluetooth-Module Feature Values Bluetooth range < 20 m (free field) Bluetooth type L Series BLE module (08 May 2013) based on TI CC254X chip Qualified Design ID B016552 Bluetooth radio class Class 3 Bluetooth company...
- Page 30 9 Authorisations and certification Shielded cables should be used for a composite interface. This is to ensure continued protection against radio frequency interference. FCC warning statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
