Trailer Vision Yard-Vue Quick Start Manual

Yard-Vue

QUICK START GUIDE

V1 Jun19

System Contents:

Camera Power
Wireless
Camera Stand
Adapter
APP Camera Antenna
x 1 x 1
x 1
Note: For video recording, ENSURE that a CLASS 10 memory card or above (8GB supplied) is utilised, as other kinds of
memory card may cause unexpected results and should be avoided.

SETTING UP THE CAMERA

1. APP DOWNLOAD
Please download and install the "OMGuard HD" APP to
your device.
For iOS
2.Power the camera
Plug the camera in to a mains supply, via the supplied power
adapter, and check that the Red & Green LEDs are flashing,
which indicates the camera is ready for Wi-Fi setup. This process
should be completed within 1min; ensure that both LEDs are
flashing Red & Green.
Note: If the LEDs are not flashing, Red & Green, press and hold the
reset button for 5 seconds until the Red & Green LEDs start to flash.
3a. Direct Wireless Connection:
(1) Go to the Wi-Fi setting on your mobile device. Choose the Wi-Fi router with a
prefix of HD-xxxxxx (xxxxxx = Camera ID numbers). Enter the default password
12345678 and 'save' the settings.
TM
USB to RJ-45 Screw Pack Quick Start
Guide
Cable
x 1 x 1 x 1 x 1
For Android
USB to RJ45
Connector
(2) Launch the APP, tap
(3) Tap (QR code icon) and scan the QR code label on the back
of the camera to bring up the DID information. Or tap "search"
and select the camera DID (also printed on the camera label).
(4) Enter the default password 123456 and 'save' the settings.
8GB Micro
SD
3b. Alternatively, establish a connection via the Ethernet cable:
x 1
(1) Connect your mobile device to the Wi-Fi router. Connect the camera to the Wi-Fi router
with the supplied Ethernet cable. After powering the camera, it will take approx 40 seconds
to connect to the router. When completed/connected the green LED will stay ON.
(2) Launch the APP, tap the "Search" button to locate the camera.
(3) Enter the default password 123456 then 'save' the settings.
4.Wi-Fi Setting
Motion 4a.
Sensor
Antenna
4b. The camera will be offline for around 40 seconds to reboot for Wifi connection. When
the camera connects to the Wi-Fi router correctly, the Green LED will stay ON.
4c. In the Wi-Fi settings of your smart phone/tablet, make sure that he Wi-Fi router you are
connecting to is the same one as the camera. If not, manually connect to it.
Note: Be sure to choose your local home Wi-Fi router on your local network in the App
ADVANCED SETTINGS. The system will begin to count down and reboot the system.
The camera view will show on screen again after the Wi-Fi setting has been updated.
Note: Wi-Fi setting may fail if you leave the ethernet cable connected. Please remove the cable
after settings have been completed.
to add the camera.
4
2
Enter Admin
Advanced
Password (default
123456)
3
Choose the appropriate
Wi-Fi router for your local
network
