Air stapler kit

Advertisement

AIR STAPLER KIT
Model 42332
ASSEMBLY AND OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
©
®
Copyright 2005 by Harbor Freight Tools
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42332 and is the answer not in the manual?

Questions and answers

Summary of Contents for Central Pneumatic 42332

  • Page 1 AIR STAPLER KIT Model 42332 ASSEMBLY AND OPERATING INSTRUCTIONS Due to continuing improvements, actual product may differ slightly from the product described herein. ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at: http://www.harborfreight.com TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
  • Page 2: Product Specifications

    It will do the job better and more safely at the rate for which it was intended. Do not modify this tool, and do not use this tool for a purpose for which it was not intended. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 2...
  • Page 3 Any part that is damaged should be properly repaired or replaced by a qualified technician. Do not use the tool if the trigger does not operate properly. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 3...
  • Page 4 Always wear ANSI approved impact safety goggles during use, maintenance, and reloading. Do not fire staples too close to the edge of a workpiece. They may split the workpiece and fly free, causing personal injury. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 4...
  • Page 5: Operation

    Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. OPERATION For best service, you should incorporate an oiler, regulator, and in-line filter, as SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 5...
  • Page 6 The Stapler should not fire if the Drive Guide (48) is not depressed against the workpiece. Make sure the Trigger (35) and Drive Guide (48) move freely, without sticking. AIR PLUG (66) TRIGGER (35) DRIVE GUIDE (48) MAGAZINE B (49) SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 6...
  • Page 7: Loading Staples

    Place a full clip of the desired appropriate size Staples (69) in the Magazine B (49). Up to 100 Staples may be loaded in the Magazine. LOCK (58) MAGAZINE A (41) MAGAZINE B (49) SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 7...
  • Page 8: Operating The Stapler

    Staples. Make sure to store the Stapler in a clean, dry, safe location out of reach of children. TRIGGER (35) DRIVE COVER (46) MAGAZINE B (49) DRIVE GUIDE (48) SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 8...
  • Page 9: Clearing Jams

    Staples. Always leave the Magazine B (49) open during maintenance. The Magazine is spring loaded, and may cause parts or a Staple to fly out of the Stapler. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 9...
  • Page 10: Inspection, Maintenance, And Cleaning

    TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 10...
  • Page 11: Parts List And Assembly Diagram

    69: 3/8”, 1/2”, 1” STAPLES (1,000 EACH) NOT SHOWN. 35 36 46 47 NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 42332 For technical questions, please call 1-800-444-3353 PAGE 11...
