更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com COLOR TELEVISION RECEIVER Chassis : SCT57C Model: CS301BGN2X/XSH CS301BN2X/XSH CS305DN2X/XSH CS305DN2X/HKX CS305DZ2X/XSH COLOR TELEVISION RECEIVER CONTENTS Precautions Specifications and IC Data Disassembly and Reassembly Alignment and Adjustments Troubleshooting Exploded View and Parts List Electric Parts List Block Diagram...
The current measured should the XÐray Protection Specifications Label, and not exceed 0.5 milliamp. Reverse the power- the Product Safety and X-ray Warning Note on plug prongs in the AC outlet and repeat the the service data schematic. test. Samsung Electronics...
Page 4
14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheat- ing, and correct any potential hazards. Samsung Electronics...
Page 5
Make sure that the portion around the serviced part has not been damaged. 8. Always connect a test instrumentÕs ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrumentÕs ground lead last. Samsung Electronics...
Page 6
4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Disassembly and Reassembly 3. Disassembly and Reassembly 3-1 Back Cover Removeal Fig. 3-1 1. After removing the screws, pull the cabinet backwards. Samsung Electronics...
Page 12
2. Remove the Anode Cap from the CRT. 3. Remove the main board by pulling it with both hands. Warning: The FBT is charged with high voltage. Before removing the Anode Cap, discharge the voltage through one of the heat sinks on the main board. Samsung Electronics...
Page 13
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Disassembly and Reassembly 3-3 Speaker Removal 1. Loosen the screws and remove the speakers. (SCREW LOOSENING POINT) Fig. 3-4 Samsung Electronics...
Page 14
(1) Always lift the picture tube by grasping it firmly around the face- plate, (2) Never lift the tube by its neck. (3) Do not scratch the picture tube or apply excessive pressure. Fractures of the glass may cause an implosion. Samsung Electronics...
ÒVOLUMEÓ keys ( Up or Down). The adjust- 7. Cancel the Adjustment Mode by re-pressing ment parameters are listed in the accompany- the ÒFactoryÓ or ÒPower onÓ keys. ing table. Select them by pressing the CHAN- NEL keys ( , ). Samsung Electronics...
Page 17
2. Access the Test Pattern parameters by pressing a CHANNEL keys ( , ) while the Service Mode is on. The cursor will move to the test pattern. Press the VOLUME keys. On-screen display: ¨ ¨ ¨ GREEN BLUE Samsung Electronics...
Page 18
( 2) SOUND SYSTEM WHEN FACTORY MODE RESET ( 3) MANUAL SEARCH DOES NOT MATTER APPLIED TO MOMO AND L INE STEREO MODEL S (ONLY) B/G & D/K ( ONLY WHEN OPTION BYTE2 : D7=1, D6=0 ( ? ) BYTE2D : D7=1, D6=1) Samsung Electronics...
Page 19
WHEN BYTE2 D0 = HIGH, NICAM MODEL: D/K STEREO F = 6.25 MHz 4-2-5 RESET The Reset Mode is used during factory inspection. Function Reset: 1. Channels Added/Erase 2. Sort 3. Language Basic (English) 4. System Auto (Non-TTX micom only) Samsung Electronics...
Page 20
Adjust the VR screen for a normal picture is tion, disconnect its AC power for at least 10 (no blooming or flyback line). minutes. 3. Adjust the FOCUS control for well defined scanning lines in the center area of the screen. Samsung Electronics...
Page 21
4 Pole Magnet 2 POLE PURITY 2 Pole Magnet 6 Pole Magnet Clamper Screw ADJUST (VERTICA YOKE CLAMP SCREW 6 POLE CONVERGENCE 4 POLE CONVERGENCE Fig. 4 -1 Convergence Magnet Assembly Vertical Green Belt 31m/m Fig. 4-2 Center Convergence Adjustment Samsung Electronics...
Page 22
Superimpose the red and the blue vertical interact, the dot movement is complex lines in the center area of the screen. (Fig. 4-3). RED/BLUE GREEN BLUE BLUE RED/BLUE GREEN 6-Pole Magnet Movement 4-Pole Magnet Movement Fig. 4-3 Center Convergence Adjustment Samsung Electronics...
Page 23
1. Input a UHF Band channel (70~80dB, 479.25MHz). 2. Adjust the AGC in the Factory mode. IC201 Pin 53 to 3.6V + 0.05V (DC). 5. Adjustment with PSL : Bottom of picture to bottom of screen. 6. Adjust PHS horizontally. Center the picture. Samsung Electronics...
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Exploded View & Parts List 6. Exploded View & Parts List 6-1 CS301BGN/XSH, CS301BN2X/XSH Samsung Electronics...
820-J 680-J R911 1.3K-J 1.1K-J R912 3.6K-J 2.2K-J R907 2.4K-J RW901 10Kx8P IC901 25PIN IC901 26PIN IC901 27PIN IC901 31PIN TP10 TP11 IC901 36PIN IC901 41PIN IC901 42PIN TP2 TP3 Powe L ne S gna L ne Samsung Electronics 11-1...
Page 56
TP16 IC201 21PIN IC201 29PIN TP21 TP18 TP19 TP13 IC201 30PIN IC201 31PIN TP14 TP21 TP20 IC201 40PIN IC201 32PIN TP22 TP23 IC201 41PIN IC201 47PIN Powe L ne TP17 TP18 TP19 TP20 S gna L ne 11-2 Samsung Electronics...
Page 57
N @ f N @ @ H g @ ? e ? I ' @ @ ? f @ ? g @ ? TP26 IC701 15 PIN TP26 TP27 TP27 IC701 18 PIN Powe L ne S gna L ne Samsung Electronics 11-3...
Page 58
? @ @ @ @ @ @ 1 ? @ @ @ e @ @ @ @ @ @ @ @ e @ @ @ @ @ @ @ ? @ @ @ ? @ @ @ @ @ ? @ @ Powe L ne S gna L ne 11-4 Samsung Electronics...
Page 59
? @ h f ? @ h f ? @ h f ? @ h f ? @ h f TP35 TP36 IC301 11PIN L402 TP38 TP37 TP37 TP38 HOUT Powe L ne S gna L ne Samsung Electronics 11-5...
Page 60
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-6 SOUND-MODULE (A2+NICAM) : Power Line : Signal Line 11-6 Samsung Electronics...
Page 62
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-8 SECAM-MODULE 11-9 PWB A/V : Power Line : Signal Line 11-8 Samsung Electronics...
Page 63
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-10 PIPTTX : Power Line : Signal Line Samsung Electronics 11-9...
Page 64
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-11 PIP-ONLY : Power Line : Signal Line 11-10 Samsung Electronics...
Page 65
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-12 TTX-ONLY : Power Line : Signal Line Samsung Electronics 11-11...
Page 66
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-13 A2 STEREO : Power Line : Signal Line 11-12 Samsung Electronics...
Page 67
更多难得资料请到江南家电维修论坛免费下载! http://bbs.520101.com Schematic Diagrams 11-14 TTX MODULE : Power Line : Signal Line Samsung Electronics 11-13...
