Samsung CS3339Z4C Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
Model:
CS3339Z4C/SHA
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
2007.04.27
CONTENTS
Precautions
Disassembly and Reassembly
Alignment and Adjustment
Troubleshooting
Exploded View and Parts List
PCB Layout Diagram
QQ :376315150
手机:13942296513

Advertisement

Table of Contents
loading

Related Manuals for Samsung CS3339Z4C

Summary of Contents for Samsung CS3339Z4C

  • Page 1 COLOR TELEVISION RECEIVER Chassis : SCT13B Model: CS3339Z4C/SHA QQ :376315150 2007.04.27 手机:13942296513 COLOR TELEVISION RECEIVER CONTENTS Precautions Specifications and IC Data Disassembly and Reassembly Alignment and Adjustment Troubleshooting Exploded View and Parts List Electric Parts List Block Diagram PCB Layout Diagram...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. JUN.1998 Printed in Korea 3SCT13B-39S104...

  • Page 3: Specifications And Ic Data

    Black stripe, 90 degree deflection 21 Inch A51KQJ63X Power Requirements: AC 100~260V, 50/60Hz Antenna Input Impedance: VHF, UHF : Telescopic dipole antenna (75 ohm unbalanced type ) Speaker Impedance 8 ohm, 5W+5W (Dual Type) 16 ohm, 3W (Monitor Type) Samsung Electronics...
  • Page 4 East : English/Czech/Croatian/Romanian/Hungarian/Polish SPM197ER TTX, English/Russian/Bulgarian Philips SPM197EP TTX, English/Iranian (TTX) SPM197EA TTX, English/French/Arabian SPM197EG TTX, English/Greek/Yugo IC902 24C04 EEPROM Zilog IC903 KiA7042P RESET IC ,W/O TTX Model KiA7442P TTX Model Philips IC401 KA7812 REGULATOR (12V) PC801 LTV817B PHOTO COUPLER Samsung Electronics...
  • Page 5 TDA8395(Pin 16) TDA4665(Pin 16) TRANSISTOR SAW-FILTER TRANSISTOR 2SD1651 UPC574J K6259K 2SD1650 KSD5072 KSA815-Y KA33V KSD5071 KSA539-Y KSD1711 E B C TRANSISTOR TRANSISTOR TDA8133 TDA8356 KSR1012 TDA6101Q KSR1010 KA7812 KSR2010 KA7809 KA78R05 E C B Fig. 2-1 Semiconductor Base Diagrams Samsung Electronics...
  • Page 6 MEMO Samsung Electronics...

  • Page 7: Alignment And Adjustment

    “VOLUME” keys ( Up or Down). The adjustment parameters are listed in the 7. Cancel the Adjustment Mode by re-pressing accompanying table, and selected by pressing the “FACTORY” or Power OFF. the CHANNEL keys ( , ). Samsung Electronics...
  • Page 8 TTX SUB-CONTRAST 0 ~ 63 STEP CATHODE DRIVE LEVEL 0 ~ 7 STEP TDA8842 BLUE STRETCH MODE 0 ~ 3 STEP NOTE : PVS,PVA, PHS, NVS, NVA,NHS parameters must be aligned using both the 50Hz and 60Hz vertical-field rates. Samsung Electronics...
  • Page 9 L (BIT : 0) L (BIT : 0) TDA8374, CK SYSTEM, RCA JACK SYSTEM OSD DISPLAY BYTE 0 : 11 L (BIT : 1) H (BIT : 0) L (BIT : 0) H (BIT : 0) L (BIT : 1) Samsung Electronics...
  • Page 10 PAL Table always used in the A/V PAL : 50KHz (PAL Table) PAL : 50KHZ (PAL Table) Mode (March 12, 1997) Sound system during the auto System search (All should be set for the system which is selected during the Factory Reset.) NT-M Samsung Electronics...
  • Page 11 CUSTOM MODE 100/50/50/50 100/50/75/50 90/50/75/50 60/50/75/50 100/50/50/50 100/50/50/50 90/50/50/50 75/55/50/50 60/50/50/50 90/55/25/50 Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. No BLUE SCREEN 4. NO TIMER (CLOCK ON/OFF) Samsung Electronics...
  • Page 12 1. Persian (for Iran) : English/Persian (Iranian) 2. Arab (Middle East, Africa) : English/French/Arabian Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. No BLUE SCREEN 4. No TIMER (CLOCK ON/OFF) Samsung Electronics...
  • Page 13 100/50/50/50 90/50/50/50 75/55/50/50 60/50/50/50 90/55/25/50 Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. No BLUE SCREEN during no RF signal (Blue screen during A/V 4. NO TIMER Samsung Electronics...
  • Page 14 Note : Unavailable during the CB model in the byte 0 NT-M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. No BLUE SCREEN 4. TIMER (CLOCK ON/OFF) Samsung Electronics...
  • Page 15 3. BLUE SCREEN ON/OFF 4. No TIMER CLOCK The SZM191ER is to be diverted to Australia/New Zealand because of the non-functionality of RGB (of pin 21). (OPTION BYTE : 55/1C)→ When using TDA8842 N1, the BLOOMING check is required. Samsung Electronics...
  • Page 16 Note : Unavailable during the CB model in the Byte 0 NT-M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal 3. BLUE SCREEN On/off 4. TIMER CLOCK ON/OFF 4-10 Samsung Electronics...
  • Page 17 Byte 0 ?) B/G & D/K OR M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal 3. BLUE SCREEN On/off 4. TIMER Clock On/Off Samsung Electronics 4-11...
  • Page 18 Byte 0 ? B/G & D/K OR M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE (during no signal) 3. BLUE SCREEN On/Off 4. No Timer Clock On/Off 4-12 Samsung Electronics...
  • Page 19 Note : Unavailable during the CD model in the Byte 0 NT-M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal 3. BLUE SCREEN On/Off 4. TIMER CLOCK On/Off Samsung Electronics 4-13...
  • Page 20 Note : Unavailable during the CD model in the Byte 0 NT-M Function Required : 1. PICTURE OFF (after 15 minutes) during no signal 2. AUDIO MUTE during no signal 3. BLUE SCREEN ON/OFF 4. No TIMER CLOCK 4-14 Samsung Electronics...

  • Page 21: Other Adjustments

    7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 8. To protect against shock hazard, use an isola- tion transformer. Samsung Electronics 4-15...
  • Page 22 STANDARD picture. 4. Adjust the Screen VR (on the FBT) so that the voltage on the oscilloscope becomes 130+2.5V (See Fig. 4-1). 130 2.5V 14, 16" :120 2.5V 20, 21" : 130 2.5V Fig. 4-1 4-16 Samsung Electronics...
  • Page 23 Mode with using CA100. See Fig. 4-4 2. Adjust RG,BG so that the levels are suitable to each local area. Fig. 4-4 (c) Low-Light Adjustment 1. Set SCT to 50.0 fL in the Factory Service Mode with using CA100. See Fig. 4-4 Samsung Electronics 4-17...
  • Page 24 5. Ensure “SD On” (Signal Input) and “SD Off” TUNER IC902 (TDA8374) (No Signal). IF (38.9MHz) 6. Adjust T201 (connected to TDA8374A pins3,4) so that AFA Bit is “INSIDE WINDOW” (the Fig. 4-6 AFB Bit is above~below). 4-18 Samsung Electronics...
  • Page 25 Fig. 4-8 6. Adjust with PHS (Horizontal Shift) : Lion head pattern and CRT centers are aligned. Fig. 4-9 7. Adjust PHS (using the width coil) so that left and right margins of the picture are 5. Samsung Electronics 4-19...
  • Page 26 MEMO 4-20 Samsung Electronics...

  • Page 27: Electric Parts List

    Electric Parts List 7. Electric Parts List 7-1 CS3339Z4C/SHA Parts List Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark ASSY-PCB,MAIN(COM) C407 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0mm, C408 2401-001530 C-AL;47uF,20%,25V,GP,TP,5x11mm,5mm BUYER : R/SHAHAB (Iran) C409 2306-000353 C-FILM,MPPF;6.3nF,5%,1.6KV,BK,26.5x8.5x16, C410 2201-000984 C-CERAMIC,DISC;680pF,10%,2KV,Y5P,TP,11x6,7.5m...
  • Page 28 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm F801A 3602-000114 FUSE-HOLDER;-,-,30mohm R213 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm F801B 3602-000114 FUSE-HOLDER;-,-,30mohm R214 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm F802 3601-001086 FUSE-FERRULE;125V,5A,QUICK-ACTING,CERAMIC,2 R215 2004-001995 R-METAL;9.1Kohm,5%,1/8W,AA,TP,1.8x3.2m HC101 AA13-20004AIC-HYBRID;-,PAP102T,SIP,6P,PRE-AMP,TP R216 2001-000490 R-CARBON;200ohm,5%,1/8W,AA,TP,1.8x3.2mm IC201 1204-001191 IC-PAL/NTSC PROCESS;TDA8374A(N3),DIP,56P,-,PLASTIC R217 2001-001411 R-CARBON;5.6Mohm,5%,1/8W,AA,TP,1.7x3.2m IC301 1204-000441 IC-IF CIRCUIT;TDA8356,SIP,9P,-,PLASTIC,40V,- R218 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m Samsung Electronics...
  • Page 29 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m RN08 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m R801 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x10mm RW702 2011-001098 R-NETWORK;75/75/1K/75ohm,5%,-,-,PLCC,5P, R802 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x10mm RX801 2002-001011 R-COMPOSITION;3.3Mohm,10%,1/2W,AA,TP,3.7x9mm R803 2004-001373 R-METAL(S);100Kohm,1%,1/2W,AA,TP,2.4x6.4m SF101 2904-001047 FILTER-SAW AV;38.9MHz,DIP10K,TP,17.1dB,PAL-B R804 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x10mm SW801 3403-001020 SWITCH-PUSH;250V,5A,DPST,OFF-ON-OFF R805 2004-001967 R-METAL(S);68Kohm,1%,1/2W,AA,TP,2.5x6.5mm SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SPST Samsung Electronics...
  • Page 30 3722-000506 JACK-RCA;2P,3.6mm,-,AG JE601 3722-000143 JACK-PHONE;1P(VER),3.4mm,AG,BLK,NO QE01 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,TP,120- RE01 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm RE02 2001-001153 R-CARBON(S);47ohm,5%,1/2W,AA,TP,2.4x6.4mm RE03 2001-000010 R-CARBON;68Kohm,5%,1/8W,AA,TP,1.8x3.2mm RE04 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm RE05 2001-000009 R-CARBON;20Kohm,5%,1/8W,AA,TP,1.8x3.2mm REMOCON AA59-10089F REMOCON;-,TM51,SZM139,27,L/GRY,NO ASSY-SPEAKER 3001-000191 SPEAKER;3W,8ohm,90dB,180Hz AA39-20503B LEAD CONNECTOR-ASSY;-,YSH025-04,REC,4P,500,1007#22 ASSY-CRT AA03-10001DCRT-COLOR;-,A34KQV42X,+380MG,14,90DEG,5 AA27-50001K DEFLECTION-YOKE;-,DSE-1422FL,14/A34KQV42X,PCL AA27-60001F MAGNET-CONVERGENCE;-,JH-225,22.5mm Samsung Electronics...

  • Page 31: Block Diagram

    TO SOUND IC B + 12.5V FBT B + 125V SWITCHING 20" FSV-20A001 KA2S0680 TRANS 21" TO µ-COM B + 5V 14" FCK-14A033 POWER-CORD TO 1CHIP B + 8V DIODE-BRIDGE D2SB60 SWITCH MULTI REGULATOR REGULATOR KA7812 KA7630 TUNER B + 9V Samsung Electronics...

  • Page 32: Wiring Diagram

    SOUND L IN SOUND L OUT SOUND R IN SOUND R OUT CN603 FRONT VIDEO IN L + OUT L - OUT 21 PIN VIDEO IN R - OUT R + OUT 21 PIN AUDIO IN FRONT AUDIO OUT Samsung Electronics 10-1...
  • Page 33 MEMO 10-2 Samsung Electronics...

  • Page 34: Schematic Diagrams

    Schematic Diagrams 11. Schematic Diagrams 11-1 TTX Micom Samsung Electronics 11-1...
  • Page 35 Schematic Diagrams 11-2 W/O TTX Micom 11-2 Samsung Electronics...
  • Page 36 Schematic Diagrams 11-3 ONE CHIP/CHROMA Block Samsung Electronics 11-3...
  • Page 37 Schematic Diagrams 11-4 IF/Sound . EXT-A/V Block 11-4 Samsung Electronics...
  • Page 38 Schematic Diagrams 11-5 Power /Vertical /Horizontal /CRT Samsung Electronics 11-5...
  • Page 39 Schematic Diagrams 11-6 A/V Front, SUB 11-6 Samsung Electronics...
