Please pay attention to the tips within the manual so as to avoid personal injury or
property losses. The tips for personal injury are indicated in warning triangles while
the tips only related to property losses have no warning triangles. The warning tips are
listed as follows with the hazardous scale from severe to slight.
Danger
If handled carelessly, death or severe human injury will occur.
Warning
If handled carelessly, death or severe human injury might occur.
Caution
Warning triangle indicates that slight human injury might occur if handled carelessly.
Note
Unexpected result or status might occur, if not handled according to the tips.
Professional Personnel
The product/system covered by the manual can only be handled by qualified and
professional personnel. During operation, please follow the respective instructive
manuals, especially the safety warnings. The professional personnel have been trained
and possess relevant experiences; therefore, he/she could be aware of the risks of the
product/system and avoid possible damages.
EVOC Product
Please pay attention to the following instructions:
Warning
EVOC product can only be used according to the descriptions within the manual,
including the contents and the relevant technical documents. If the products or
components from other companies are required, please get the recommendation and
grant from EVOC first. Proper transportation, storage, assembly, installation,
debugging, operation and maintenance are prerequisite to ensure product safety and
normal operation; therefore, please ensure permitted environment conditions and pay
attention to the tips within the manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EVOC NPC-8210
Summary of Contents for EVOC NPC-8210
- Page 1 Please pay attention to the following instructions: Warning EVOC product can only be used according to the descriptions within the manual, including the contents and the relevant technical documents. If the products or components from other companies are required, please get the recommendation and grant from EVOC first.
- Page 2 Trademarks EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other product names mentioned herein are used for identification purposes only and may be trademark and/or registered trademarks of their respective companies.
- Page 3 About this manual Scope of the Manual The manual is appropriate for EVOC NPC-8210. Convention The term “the PC” or “the Product” within the manual usually stands for EVOC NPC-8210. Instructions Safety instructions To avoid property losses or individual injury, please pay attention to the safety instructions within the manual.
-
Page 4: Table Of Contents
Contents 1. Product Introduction ....................1 1.1 Overview .......................1 1.2 Specifications ....................1 2. Application Scheme ....................5 2.1 Transportation....................5 2.2 Storage......................5 2.3 Opening the Box and Initial Examination............6 2.4 Mounting Method..................6 3. Device Connection....................7 3.1 Notes before Connection ................7 3.2 Product Grounding ..................7 3.3 Connecting the Device to Power ..............8 4. - Page 5 4.6 Indicators .....................17 4.7 IPMI instructions ..................18 4.8 Using System Setup Program and UEFI Boot Manager ......22 5. Assembly and Maintenance ..................29 5.1 Overall Assembly Drawing................29 5.2 Opening the Cover..................31 5.3 Installation and Removal of Motherboard ...........31 5.3.1 Installing the Motherboard ..............31 5.3.2 Removing the Motherboard.............32 5.4 Installation and Removal of HDD ...............32 5.5 Installation and Removal of Power Supply..........33...
-
Page 6: Product Introduction
Product Introduction 1. Product Introduction 1.1 Overview NPC-8210 is a high-performance network application platform based on X86 architecture. The machine adopts standard 2U, 19-inch rack mount and modular design, which is convenient for network and storage expansion. IPMI and intrusion detection functions are supported, to meet various network application requirements. - Page 7 Provides 1 x CF card slot (expanded via EF-EIO-043NPC board); Provides interface (expanded EF-EIO-043NPC board), used for DOM expansion (This interface and CF card cannot be used at same time); Provides 1 x PS/2 keyboard/mouse port; - 2 - NPC-8210...
- Page 8 (operating BurnIntest， operating CPU、 MEM 100%). Notes: 1. NPC-8210-01 supports up to 24 1000Mbps LAN ports/provides one standard PCIE x8 slot/two 3.5-inch drawable HDD/single power supply; 2. NPC-8210-02 supports up to 40 1000Mbps LAN ports/4 x 2.5-inch drawable NPC-8210...
- Page 9 Product Introduction HDD/redundant power supply; 3. NPC-8210-03 supports up to 24 1000Mbps LAN ports/provides one standard PCIE 8X slot/2 x 3.5-inch drawable HDD/redundant power supply; 4. NPC-8210-05 supports up to 40 1000Mbps LAN ports/2 x 2.5-inch drawable HDD/redundant power supply;...
-
Page 10: Application Scheme
Under this circumstance, please make sure no water drop (condensation) is formed on the surface or interior of the device. If condensation is formed on the device, please wait for over twelve hours before connecting the device. NPC-8210 - 5 -... -
Page 11: Opening The Box And Initial Examination
● Please check whether the delivery contains the intact device and all of the independently ordered accessories. Please contact the customer service when any unconformity or transportation damages occur. 2.4 Mounting Method ■19″ Rack Mount □Desktop □Embedded Panel □Wall Mount □VESA Standard Arm □Portable □Others___________ - 6 - NPC-8210... -
Page 12: Device Connection
Ground Terminals Connect the grounding wire to the ground screw of the chassis. The minimum cross section area of the cable shall be no less than 5mm the grounding locations of NPC-8210 NPC-8210 - 7 -... -
Page 13: Connecting The Device To Power
NPC-8210 single power supply Steps to connect the device to power: Connect the power cable to the redundant power supply AC power connector, please confirm... -
Page 14: Operating Instructions
Operating Instructions 4. Operating Instructions 4.1 Outer Appearance NPC-8210 (used with NET-2814VD2N(B)-01 motherboard) Different configuration, slight difference in outer appearance. In this picture, the front panel supports expansion to ENC card NPC-8210 (used with NET-2814VD2N(B)-02 motherboard) Different configuration, slight difference in outer appearance. In this picture, the front panel supports four 2.5-inch HDD trays as full configuration. -
Page 15: Product External Dimensions And Installation Dimensions
NET-2814VD2N(B)-01 used with NET-2814VD2N(B)-02 motherboard motherboard Unit: mm 4.2.2 Installation Dimensions Drawing NPC-8210 product installation dimensions drawing. The front panel may vary slightly based on the mated motherboard and configuration. used with NET-2814VD2N(B)-01 motherboard - 10 - NPC-8210... -
Page 16: External Structure
Operating Instructions used with NET-2814VD2N(B)-02 motherboard Unit: mm 4.3 External Structure NPC-8210 (used with NET-2814VD2N(B)-01 motherboard) Front view of the device Item Description ① Reset button ② ③ CONSOLE port ④ ETH-A/IPMI port ⑤ ETH-A/ETH-B Drawable ENM module ⑥ ENC module(optional) ⑦... - Page 17 Description Drawable ① module BYPASS switch ② ③ Ground screw ④ Power ⑤ Power switch ⑥ NPC-8210(used with NET-2814VD2N(B)-02 motherboard) Front view of the device Item Description Reset button ① ② ③ CONSOLE port ④ ETH-A/IPMI port ⑤ or ETH-A/ETH-B Drawable ⑥...
-
Page 18: Port Definition
(single color: Network activity green) green) 1000Mbps Green Data being transmitted Yellow Flash 100Mbps No data being 10Mbps transmitted 2. The front panel provides one 10/100Mbps RJ45 IPMI management port LAN2. Its pin definition is as follows: NPC-8210 - 13 -... -
Page 19: Usb Port
Wake-On-LAN. Their pin definitions are the same with LAN1 on the front panel. 4.4.2 USB Port The front panel provides two front-accessible USB ports. Their pin definitions are as follows: Signal Name +5V_USB USB_DATA- USB_DATA+ - 14 - NPC-8210... -
Page 20: Com Port
Its pin definition is as follows: Signal Name RTS# DTR# COM1 DSR# CTS# 4.4.4 Display Port The rear panel provides one VGA port. Its pin definition is as follows: Signal Signal Name Green Blue DDCDATA HSYNC VSYNC DDCCLK NPC-8210 - 15 -... -
Page 21: Operation Control
Reset button. Use a pointed object or a clip to operate the reset button. This button will ② trigger hardware reset. The device executes reboot (cold reset) - 16 - NPC-8210... -
Page 22: Indicators
Operating Instructions 4.6 Indicators NPC-8210-01: Indicator Meaning Description Disconnected from power Device status Gree Device is running No access Access to the hard drive Yellow Being accessed No data communication ACTLED status Green Data communication Not linked or10Mbps ETH-A Green... -
Page 23: Ipmi Instructions
Get CPU1 temperature, and input on CLI interface get_cpu1_temperature cpu1_temperature=56℃ cli>get_cpu1_temperature Get CPU2 temperature, and input on CLI interface get_cpu2_temperature cpu2_temperature=54℃ cli>get_cpu2_temperature Get system fan 1, and input on CLI interface get_sysfan1_speed sysfan1_speed=4515rpm cli > get_sysfan1_speed - 18 - NPC-8210... - Page 24 Get vbat voltage value, and input on CLI interface get_v_bat_value v_bat_value=3.152V cli>get_v_bat_value sys_temperature =53℃ cpu1_temperature=57℃ Detect hardware information, and input on CLI cpu2_temperature=0℃ interface sysfan1_speed=0rpm hwmonitor cli > hwmonitor sysfan2_speed=0rpm sysfan3_speed=0rpm cpufan1_speed=2033rpm cpufan2_speed=0rpm NPC-8210 - 19 -...
- Page 25 Check current temperature alarm threshold values. get_cpu1_threshold For example, input on CLI interface sys_threshold：80 80 80 get_cpu2_threshold cli > get_sys_threshold Reset system, and input on CLI interface reset_system cli>reset_system Start system, and input on CLI interface start_system cli>start_system - 20 - NPC-8210...
- Page 26 Set IPMI system time, and input on CLI interface set_time 2013-1-1 13:00 cli > set_time Disconnect telnet link, and input on CLI interface disconnect cli >disconnect Reset IPMI, and input on CLI interface reset_ipmi cli >reset_ipmi NPC-8210 - 21 -...
-
Page 27: Using System Setup Program And Uefi Boot Manager
<Ctrl>+<S> refer to “Using System Setup Program”） , which is only applicable to NPC-8210 complete PC. System setup boot program is a BIOS program, an option which enables you to manage system hardware and designated BIOS class. By system setup program, you can: ... - Page 28 Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Boot →←：Select Screen Boot option filter [legacy Only] ↑↓：Select Item Launch PXE OpROM policy [Do not launch] Enter：Select +/-：Change Opt F1：General Help F2：Previous Values F3：Optimized Defaults F4：Save ESC：Exit Version 2.15.1222226. Copyright (C) 2012,American Megatrends, Inc. NPC-8210 - 23 -...
- Page 29 The following sections list the system setup program options you may make changes. As for the detailed explanations about the functions of option, please refer to the “BIOS Setup” chapter in the motherboard user manual CD. - 24 - NPC-8210...
- Page 30 Note: The options of system setup program may vary with system configurations. Table 5 Main Screen Setup Option Description System Date Set up the date within the system. System Time Set up the time within the system. NPC-8210 - 25 -...
- Page 31 The options include IDE mode and AHCI mode. Enable or disable HDD hotswap function under AHCI mode. Port 1 ～ 6 Hot Note: It can be used only when it is supported by driver under Plug operating system. - 26 - NPC-8210...
- Page 32 Set up the system status upon reboot after the PC is disconnected from AC power. Restore AC Power Loss PowerOff: The system is powered off. PowerOn: The system is powered on automatically. Last State: It returns to the status before power loss. NPC-8210 - 27 -...
- Page 33 Exit the Interafce Press <ESC> to exit the system setup program, to display Exit interface. Table 14 Exit the Interface Option Description Save Changes and Reset Save changes and exit Discard Changes and Exit Discard changes and exit - 28 - NPC-8210...
-
Page 34: Assembly And Maintenance
5.1 Overall Assembly Drawing Item Description Item Description Item Description Mounting ear Chassis Rear mount ear Drawable fan Power supply Wind shield module Motherboard Chassis cover Front cover 3.5-inch drawable Expansion module(optional) NPC-8210 is used with NET-2814VD2N(B)-01 motherboard NPC-8210 - 29 -... - Page 35 Item Description Item Description Item Description Mounting ear Chassis body Rear mounting Drawable fan module Power supply Wind shield Motherboard Chassis cover Front cover 2.5-inch drawable Expansion module (Optional quantity) NPC-8210 is used with NET-2814VD2N(B)-02 motherboard. - 30 - NPC-8210...
-
Page 36: Opening The Cover
5.3 Installation and Removal of Motherboard 5.3.1 Installing the Motherboard 1. Place the motherboard inside the chassis, use ten M3 pan head combo screws to fasten it. 2. Use seven M3*6 hex copper studs to fasten the motherboard memory module. NPC-8210 - 31 -... -
Page 37: Removing The Motherboard
5.4 Installation and Removal of HDD NPC-8210 is used with NET-2814VD2N(B)-01 motherboard, and has two 3.5-inch drawable HDD. Use the key in the accessory kit to open the lock on the HDD case, grasp the handle on the case and pull it outward to take out the 3.5-inch HDD from the chassis, so as to replace or install HDD. -
Page 38: Installation And Removal Of Power Supply
5.5 Installation and Removal of Power Supply 5.5.1 Installing the Power Supply When NPC-8210 is equipped with single power supply, use six M3 sunkhead screws to fasten the power bracket onto the chassis, place the power supply inside the chassis,... - Page 39 Assembly and Maintenance NPC-8210 is equipped with redundant power supply, use six M3 sunkhead screws to fasten the power bracket onto the chassis body, place the power supply inside the chassis, use four sunkhead #6-32*1/4 screws to fasten the power supply onto the bracket, then use one M3 combo screw to fasten the tail end of the power supply onto the chassis from inside of the chassis.
-
Page 40: Removing The Power Supply
5.6 Installation and Removal of Fan 5.6.1 Installing the Fan NPC-8210 adopt externally rawable fans, and the cables can be inserted or pulled out outside the chassis. Reach your fingers into the fan hole to insert the fan terminal outside the chassis, push the fan module into the fan hole, then tighten the two M3... -
Page 41: Removing The Fan
Lay the fan on the table, and reach your fingers into the fan hole to pull out the cable terminal, as shown in the figure below: Attention! Because the fans rotate at fast speed, do not touch the fans before they stop working. - 36 - NPC-8210... -
Page 42: Special Installation Instructions
Directly align the brackets with hex studs and tighten the screws. 5.7.2 CF Card Reinforcement Install step screws with gasket on the CF card reinforcement brackets. These screws will not fall out from the brackets. Directly align the brackets with hex studs and tighten the screws. NPC-8210 - 37 -... -
Page 43: Installing Enc Modular Card (Optional)
Assembly and Maintenance 5.7.3 Installing ENC Modular Card (optional) When NPC-8210 is used with NET-2814VD2N(B)-01 motherboard, it can choose ENC Modular Card. The installation stepsare as follows:align the converter board gold finger of ENC modular card with PCIE slot of the motherboard, insert the card downward with force to the bottom of the slot, then use two sunkhead screws to fasten 5.7.4 Installing the CPU Fans... -
Page 44: Installing The Drivers
Installing the Drivers 6. Installing the Drivers Regarding the installation of the driver program and the detailed information of the motherboard, please refer to the enclosed CD of the PC. NPC-8210 - 39 -... -
Page 45: Appendix
Follow the power-on prompt and Incorrect time or press the key to enter the BIOS Incorrect BIOS setting date on device Setup; adjust the time and date in BIOS Setup. - 40 - NPC-8210... - Page 46 Enter the system (usually WinPE system) with a bootable disk; System files on the hard check whether the system in the disk are damaged. hard disk is damaged. Reinstall the system if necessary. NPC-8210 - 41 -...
- Page 47 IO Poor contact of the slot. card, unstable fixing or improper card can be used dust-proof measures; please when used again. remove and install the card for a few times or use another slot. - 42 - NPC-8210...
