Owner's Manual
• A recreational vessel designed for use on internal waterways with an expected wind strength reaching
Grade 4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres inclusive, with
occasional waves up to 0.5 metres of height caused e.g. by vessels passing by.
• The boat has been manufactured in compliance with the EN ISO 6185-1 Standard, Category IIIB.
• Related standards: EN ISO 10087, EN ISO 10240, EN ISO 14945.
Dear Customer,
This manual will help you to easily and safely master your vessel.
It contains a detailed description of the vessel, the supplied or built-in
equipment, its sets as well as information about its control and mainte-
nance. Please read it carefully, thereby getting to know the boat before
actually using it.
If this is your fi rst vessel or you have changed the type of vessel and
do not know this type well, please get acquainted with its maintenance
and control prior to your fi rst individual use of the vessel so that it is safe
and comfortable. Your dealer or the National Yacht Federation or club
will recommend you appropriate training courses or qualifi ed instructors.
Do not pull off until the expected sailing conditions (wind strength and
wave height) are appropriate for the construction category of your vessel
and you and your crew are able to control it in these conditions.
Please store this manual in a safe place and hand it over to the new
owner should you sell the vessel.

1. Table of specifications

(Dimensions when infl ated)
Length (cm) [ft./in.]
Width (cm) [ft./in.]
Diameter of sidewall cylinders (cm)
Number of air chambers
Approximate dimensions – packed in transportation
bag (cm) [in.]
Dimensions – packed in cardboard (cm) [in.]
Maximum operational pressure
Weight (kg) [lbs.]
Maximum load (kg) [lbs.]
Maximum number of kayakers
Draught (cm) [in.]
Highest anchor above surface (cm) [in.]
TWIST 1 LN, TWIST 2 LN
TABLE OF CONTENTS:
1. Table of Specifi cations
3. Infl ation Instructions
4. Using the Canoe
5. Folding of the boat
8. Boat Repairing
TWIST 1 LN
260 [8/6]
79 [2/7]
21
3 + 2
54 × 34 × 20 [21 × 13 × 8]
57 × 42,5 × 25 [22 × 17 × 10]
0,02 MPa [0,2 Bar/3 PSI]
7,4 [16,3]
100 [220]
1
15 [6]
35 [14]
VERSION 1/2018
USA
page 1
TWIST 2 LN
360 [11/10]
83 [2/7]
21
3 + 3
54 × 37 × 23 [21 × 15 × 9]
57 × 42,5 × 25 [22 × 17 × 10]
0,02 MPa [0,2 Bar/3 PSI]
11 [24]
180 [397]
2
15 [6]
35 [14]
1
2
2
2
3
3
3
3
3
3
4
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWIST 1 LN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Innova TWIST 1 LN

  • Page 1 TWIST 1 LN, TWIST 2 LN VERSION 1/2018 Owner’s Manual • A recreational vessel designed for use on internal waterways with an expected wind strength reaching Grade 4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres inclusive, with occasional waves up to 0.5 metres of height caused e.g.
  • Page 2 2. Technical description – see Fig. 1 4. Using the kayak 1. side cylinder The TWIST kayak is a single-seat infl atable kayak. Whenever 2. bottom the kayak is used on waterways, Waterway Traffi c Rules 3. PUSH/PUSH valve – enables infl ation/ exhaustion, pres- should be observed.
  • Page 3 Or in North America by INNOVA: and which impregnates the material to prevent further dirtying, Innova Kayaks by GUMOTEX USA or which is capable of forming a protective UV-fi...
  • Page 4 The Guarantee Certifi cate is attached to this manual. Explanation of the symbols used: maximum operational pressure maximum number of people maximum load Innova Kayaks by Gumotex European Infl atable Touring Kayaks 1 Chestnut Street, Suite 222, Nashua, NH 03060, USA Tel.: (360) 707-2855, E-mail: info@innovakayak.com www.innovakayak.com...
