Innova THAYA Owner's Manual

Owner's Manual
• A recreational vessel designed for use on internal waterways with an expected wind strength reaching
Grade 4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres inclusive, with
occasional waves up to 0.5 metres of height caused e.g. by vessels passing by.
• The boat has been manufactured in compliance with the EN ISO 6185-1 Standard, Category IIIB.
• Related standards: EN ISO 10087, EN ISO 10240, EN ISO 14945.
Dear Customer,
This manual will help you to easily and safely master your vessel.
It contains a detailed description of the vessel, the supplied or built-in
equipment, its sets as well as information about its control and mainte-
nance. Please read it carefully, thereby getting to know the boat before
actually using it.
If this is your first vessel or you have changed the type of vessel and
do not know this type well, please get acquainted with its maintenance
and control prior to your first individual use of the vessel so that it is safe
and comfortable. Your dealer or the National Yacht Federation or club
will recommend you appropriate training courses or qualified instructors.
Do not pull off until the expected sailing conditions (wind strength and
wave height) are appropriate for the construction category of your vessel
and you and your crew are able to control it in these conditions.
Please store this manual in a safe place and hand it over to the new
owner should you sell the vessel.
1. Table of Specifications
(indicative values)
Length (cm) [ft./in.]
Width (cm) [ft./in.]
Number of air chambers
Side tube diameter (cm) [in.]
Dimensions – packed in carry bag (cm) [in.]
Outer dimensions of the carton (cm) [in.]
Maximum operational pressure - Sidewall cylinder
- Bottom
Weight (kg) [lbs.]
Load (kg) [lbs.]
Maximum number of people
Draught (cm) [in.]
The highest anchor above surface (cm) [in.]
2. Technical Description – See Picture 1
1. Side barrel
2. Bottom
3. PUSH/PUSH valve – allows inflating/deflating, pressure
regulation and measuring the pressure using a pressure
gauge
4. Manufacturer's label
5. Yellow "WARNING" label
6. Inflatable seat
7. Front footrest
8. Rear footrest
9. Board
THAYA
KAYAK
TABLE OF CONTENTS:
1. Table of Specifications
2. Technical Description
3. Inflation Instructions
4. Using the Boat
5. Storage of the Boat
6. Treatment and Storage
7. Guarantee Conditions
8. Boat Repairs
9. Product Disposal Method
1 0. Packaging Disposal Method
1 1. Manufacturer's Label
– legend of symbols used
1 2. Safety Caution
63 × 40 × 26 [25 × 16 × 10]
70 × 47,5 × 32 [28 × 19 × 13]
0,02 MPa [0,2 Bar/3 PSI]
0,05 MPa [0,5 Bar/7,2 PSI]
1 0. Safety rope
1 1. Handle
1 2. Drain hole
1 3. Flexible rope with snap hooks
1 4. Bracket for fastening the seat and footrest
1 5. Bracket for fastening the seat
1 6. Bracket for fastening the front footrest
1 7. D-ring for fastening the backrest
1 8. Backrest straps
1 9. Flexible rope for fastening baggage
2 0. Tracking fin bracket
2 1. Screw valve for small chambers (seats, footrests, etc.)
2 2. Plastic seat buckle
VERSION 1/2019
USA
Page 1
THAYA
410 [13/5]
89 [2/11]
3 + 2/4/6 + 2
22 [8.7]
17,5 [39]
230 [507]
2 + 1 Child
15 [6]
54 [21]
1
1
2
2
3
3
3
3
3
3
4
4
