Innova Solar 410C User Manual

User's Manual
•
A recreational vessel designed for use on internal waterways with an expected wind strength reaching
Grade 4 on the Beaufort Scale inclusive and a determining wave height of up to 0.3 metres inclusive, with
occasional waves up to 0.5 metres of height caused e.g. by vessels passing by.
•
The boat has been manufactured in compliance with the EN ISO 6185-1 Standard, Category IIIB.
•
Related standards: EN ISO 10087, EN ISO 10240, EN ISO 14945.
Table of Contents:
Dear Customer,
This manual will help you to easily and safely master your vessel.
It contains a detailed description of the vessel, the supplied or built-in
equipment, its sets as well as information about its control and mainte-
nance. Please read it carefully, thereby getting to know the boat before
actually using it.
If this is your fi rst vessel or you have changed the type of vessel and
do not know this type well, please get acquainted with its maintenan-
ce and control prior to your fi rst individual use of the vessel so that it
is safe and comfortable. Your dealer or the National Yacht Federation
or club will recommend you appropriate training courses or qualifi ed
instructors.
Do not pull off until the expected sailing conditions (wind strength and
wave height) are appropriate for the construction category of your ve-
ssel and you and your crew are able to control it in these conditions.
Please store this manual in a safe place and hand it over to the
new owner should you sell the vessel.
1. Table of Specifications
(Dimensions When Infl ated)
Length (cm) [ft./in.]
Width (cm) [ft./in.]
Number of fair chambers
Approximate dimensions-packed in carry bag (cm) [in.]
Dimensions-packed in cardboard (cm) [in.]
Maximum operational pressure (MPa) [Bar/PSI]
Weight (kg) [Ibs.]
Maximum load (kg) [Ibs.]
Maximum number of people
Draught (cm) [in.]
Highest part of boat above waterline (cm) [in.]
2. Technical Description – See Picture 1
1. Sidewall cylinder
2. Bottom
3. PUSH/PUSH valve – for infl ating/defl ating the kayak,
regulating pressure and measuring pressure using a ma-
nometer
4. Front seat
5. Rear seat
6. Front foot-rest
7. Rear foot-rest
8. Rotational valve for minor chambers (seats, foot-rests,
etc.)
9. Deck
10. Handle
SOLAR 410C
1. Table of Specifi cations
2. Technical Description
3. Infl ation Instructions
4. Using the Boat
5. Storage of the Boat
6. Treatment and Storage
7. Guarantee Conditions
8. Boat Repairs
9. Product Disposal Method
10. Packaging Disposal Method
11. Manufacturer's Label
– legend of symbols used
12. Safety Caution
54 × 39 × 24 [21 × 15 × 9]
70 × 43 × 26 [28 × 17 × 10]
0,02 MPa [0,2 Bar/3 PSI]
11. Safety rope
12. Manufacturer's Label
13. Yellow "CAUTION" label
14. Flexible mesh for baggage
15. Rudder blade fi xture
16. Seat and foot-rest fastening strap
17. Seat fastening strap for single-seat confi guration
18. Rear seat fastening strap
19. Front foot-rest fastening strap
20. Seat fi xation D-ring
21. D-ring for fastening objects by means of a snap-hook
22. Backrest fi xation straps
23. Seat plastic clip
24. Rear plastic clip
25. Safety relief valve
