Mäktig 601625 Instruction Manual

Electric
Drum Pump
Electric drum pump designed for
pumping fuels, water based media, light
oils, DEF & select chemicals from metal
drums of 55 gallon (205 litre or 275-330
gallon (1000-1250 litre) IBC's
Compact & lightweight construction
Convenient ON/OFF Switch with LED
Indicator
Built-in fuse for overload protection
Silenced motor makes almost no noise
Stainless steel filter built into the suction
tube inlet prevents contaminants from
getting in & causing damage
Built-in 2" bung adaptor fits directly onto
metal drums of 55 gallon (205 litre). Bung
adapter can be adjusted by 0.6" (15 mm)
to adjust to drums with varying heights.
Includes an additional bung thread
converter for converting 2" standard bung
threads to 2.5" X 5 mm buttress for using
pump with IBC's
Telescopic suction tube extends from 33-
1/2" (850 mm) to 49" (1245 mm) for use
with 55 gallon (205 litre) drums or 275-
330 gallon (1000-1250 litre) IBC's
Supplied complete with 2m (6.6') hose &
manual dispensing nozzle with 3/4" (19
mm) OD Stainless Steel Spout
Duty Cycle: 15 minutes On /
15 Minutes Off
WETTED COMPONENTS
Viton, Acetal (POM), Stainless Steel (SS),
Polyethaline (PE), Polypropylene (PP),
Nitrile Butadiene Rubber (NBR)
RECOMMENDED USE
Diesel, Kerosene, Bio Diesel, DEF/
Adblue, Water based media, Antifreeze,
Detergents, Pesticides Herbicides, Urea,
Light oils with viscosity upto 100 cst
FEATURES
DELIVERS
UPTO
28 LPM
(7.4 GPM)
FLUIDS
DIESEL KEROSENE
Lift Handle
18.5V, 1.3Ah Li-Ion
Battery
Thread Converter
(with 2.5" X 5 mm
Buttress Threads)
Telescopic
Suction Tube
SS Strainer
! WARNING:
Failure to follow all safety information can result in death, personal injury and/or property damage.
• Do Not Use With: Gasoline, Corrosive chemicals, Lacquer thinners, or any material that is not
compatible with the pump construction.
• Keep all sources of fire away from the pump.
• Wear safety glasses at all times when working with this pump.
• Wear a face shield, proper apparel and suitable respiratory equipment when pumping hazardous
chemicals.
• In case of accident, immediately seek medical attention. Do not try to treat the injury yourself.
• Keep work area clean, uncluttered and properly lighted.
• Use only genuine factory parts for repair.
BIO DIESEL DEF / ADBLUE WATER ANTIFREEZE DETERGENTS
INSTRUCTION MANUAL
On/Off Switch
Pump outlet
with swivel
connection
Flexible
Corrugated Hose
2m (6.6') long
PESTICIDES
UREA
HERBICIDES
601625
3/4" (19mm)
SS Spout
Manual
Dispensing
Nozzle
Nozzle
Holster
LIGHT OIL
6
