Assembly Instructions & Safe Anchoring Guide iss.1
To be retained in the Owners manual
LFX Parts List
Clips set
(Clip, Nut, Bolt)
Crown
Mud Palms
Fixing Kit
Mud Palms
Shank
Stock
1. Fix the mud palms to the top
and bottom of the crown, using
8mm nuts & bolts.
2. Insert the shank into the crown and place stock
through the crown and shank.
3. Slide flukes into the groves both sides of the
crown.
Fluke
4. Using a ruler or tape
measure, centre stock in the
anchor accurately.
5. Slide clips onto stock and fix through the flukes and
tighten nuts and bolts.
Lewmar LFX Assembly Instructions & Safe Anchoring Guide iss.1
|
1
