CaratteristiChe • FeatUres
Pattumiera ad estrazione totale da 300 mm Lt. 32
Full extension wastebin 300 mm Lt. 32
MinUteria interna • Fittings
n°12 3,9x13 Vite autofilettante TC a croce / Self tapping screws TC
n°8 4x16 Vite autofilettante TSP a croce/ Self tapping screws TSP
n°4 M4x5 Vite cilindrica / Cylinder screw
CoMponenti • parts
A. n°1 Box metallico / Metal box
B. n°1 Coperchio / Lid
C. n°1 Kit guide Sige / Kit Sige slides
D. n°1 Coppia carter guide / Kit slide carter
E. n°2 Lamiera reggi coperchio / Metal plate
F. n°1 Secchio piccolo 6 Lt. / Small bin Lt. 6
G. n°1 Secchio grande 24 Lt. / Big bin Lt. 24
H. n°1 Coppia attacco antina / Kit door fixing brackets
I. n°2 Squadretti stabilizzatori antina / Door stabilising elements
L. n°2 Cover attacco antina / Door fixing cover
