MODULAR CRESCENT CUBER
INSTRUCTION MANUAL
No. 15 Qingqiu Street, Suzhou Industrial Park, Suzhou 215126 China
KMD-201AA
KMD-201AWA
KMD-270AA
KMD-270AWA
L1F037115 (060118)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KMD-201AA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hoshizaki KMD-201AA

  • Page 1 MODULAR CRESCENT CUBER KMD-201AA KMD-201AWA KMD-270AA KMD-270AWA INSTRUCTION MANUAL No. 15 Qingqiu Street, Suzhou Industrial Park, Suzhou 215126 China L1F037115 (060118)
  • Page 2: Table Of Contents

    IMPORTANT SAFETY INFORMATION ............................1 I. INSTALLATION INSTRUCTIONS ..............................3 1. UNPACKING ..................................3 2. LOCATION ...................................3 3. INSTALLATION ..................................3 4. BIN CONTROL INSTALLATION ............................3 5. ELECTRICAL CONNECTIONS ............................4 6. WATER SUPPLY AND DRAIN CONNECTIONS .........................4 II. OPERATING INSTRUCTIONS ..............................5 1. OPERATION ..................................5 2.
  • Page 3: Important Safety Information

    ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury.
  • Page 4 * If the supply cord is damaged, it must be replaced by a replacement cord available from Hoshizaki Parts / Service Centres. * Do not touch the electrical parts or operate the switches with damp hands. * This appliance is not intended for use by persons (including children) with reduced physical,...
  • Page 5: Installation Instructions

    ENGLISH I. INSTALLATION INSTRUCTIONS 6. Do not place anything on top of the icemaker or in front of the louver. 1. UNPACKING 7. This icemaker will not work at subfreezing temperatures. To WARNING prevent damage to the water supply line, drain the icemaker Children should not be allowed in reach of the packaging elements when air temperature is below zero (see “II.
  • Page 6: Electrical Connections

    ENGLISH 6) Route the bin control lead through the hole in the base, then into the 11) Secure the pump motor bracket with the two thumbscrews. bushing provided. See Fig. 4. 12) Reconnect the pump motor connector and float switch connector. 13) Replace the front insulation and front panel in their correct positions. 5.
  • Page 7: Operating Instructions

    ENGLISH * The icemaker drain line must be run separately from the storage bin/ dispenser unit drain line. Icemaker Water Supply Inlet Icemaker 1/2”FPT II. OPERATING INSTRUCTIONS WARNING 1. This icemaker is designed to produce edible ice. To keep the icemaker hygienic: Icemaker * Wash your hands before removing ice.
  • Page 8: Before Calling A Service Agent

    Hoshizaki’s liability under the terms of the warranty are limited and twice per month: shall exclude routine servicing, cleaning, essential maintenance and/or repairs occasioned by misuse and installations not in accordance with 1) Remove the air filter.
  • Page 9: Disposal

    Pressure (0.7 - 8 bar) (0.7 - 8 bar) V. SPECIFICATIONS Voltage Range 207 - 254V 207 - 254V Model KMD-201AA KMD-201AWA Type Air-cooled, crescent cube Water-cooled, crescent This product includes a hermetically sealed refrigeration system cube ice that contains fluorinated greenhouse gases.
