Light & Motion CLx Owner's Manual

OWNER'S MANUAL
DETAILED OPERATIONS
OLED DISPLAY
Overheating Icon
Thermal Sensor is not Detect
Return unit to Light and Motion for
Wait to charge until
servicing.
symbol disappears
LED is not detected
LED
POWER
90
8000
MIN
LUMENS
OPERATION SPECIFICATION
AUTO FAN OPERATION
Auto fan behavior
0-4000 lumens - fan off
4000+ to 6400 lumens - fan low
over 6400 lumens - fan high
charging - fan low
CARE & MAINTENANCE
• Maintain o-rings with a light coating of silicone grease to preserve seal.
• Clean charge terminals with rubber pencil eraser or cotton-tipped or foam-tip
swab with vinegar/water solution.
STORAGE & TRAVEL
• Never store the lights with the batteries fully discharged as this may cause
permanent damage to the batteries.
• Store your light partially to fully charged for long life.
• Do not leave lights in direct sun or stored in hot location.
Turn power switch off for travel.
•
Always operate the CLx with a DM modifier installed to protect the LED from dust
•
and moisture.
INCLUDED MODIFIERS
• FLAT PORT DM
ELINCROM MODIFIER
MOUNT
YS MOUNT W/
UMBRELLA HOLDER
INCLUDED
HIGH LEVERAGE MOUNTS
HANDLE
THUMB SCREW
C-STAND MOUNT
Overheating icon
External Power Detected
Light Operating With
External Power
Battery Status
Lumen/Percentage Output
8000/5000
OPERATING THE CLx WITH
SOFTBOXES
When using 3rd-Party modifers that cover
the heat sink, trapped heat can cause
the light to lower it's output. To prevent
overheating, open the modifier vents or
dial back to a lower lumen output.
OPERATION
Power Knob
MODE
Short Press = ON/OFF
Long Press = Menu Settings

MENU DISPLAY

110w
MENU CONTROLS
Short Press: Moves Up
Short Press: Cycles through settings
Long Press: Enter / Exit
Short Press: Moves Down
OPERATING FROM EXTERNAL POWER
Light will operate best on external power if internal battery is charged
60% or more. If the light is run off wall power with an empty battery,
the extra heat generated while charging may reduce the output.
* The light will run at full power off external external source as long as
1- the battery is charged to 60% or more
2- power supply minimum 110Watt
