Garmin GPSMAP 8400 Series Installation Instructions Manual

GPSMAP 8400/8600 SERIES
®
INSTALLATION
INSTRUCTIONS
Important Safety Information
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
When connecting the power cable, do not remove the in-line
fuse holder. To prevent the possibility of injury or product
damage caused by fire or overheating, the appropriate fuse
must be in place as indicated in the product specifications. In
addition, connecting the power cable without the appropriate
fuse in place voids the product warranty.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
When drilling or cutting, always check what is on the opposite
side of the surface.
To obtain the best performance and to avoid damage to your
boat, install the device according to these instructions.
Read all installation instructions before proceeding with the
installation. If you experience difficulty during the installation,
contact Garmin Product Support.
®
Contacting Garmin Support
• Go to support.garmin.com
product manuals, frequently asked questions, videos, and
customer support.
• In the USA, call 913-397-8200 or 1-800-800-1020.
• In the UK, call 0808 238 0000.
• In Europe, call +44 (0) 870 850 1241.
Updating the Device Software
You may need to update the device software when you install
this device or add an accessory to the network. You can use
one of two methods to update the software.
• Use the ActiveCaptain
™
• Download the update from
/software/marine.html using a memory card (32 GB max.)
and a computer running Windows
For more information, see the owner's manual at
www.garmin.com/manuals/GPSMAP84xx-86xx.
Registering Your Device
Help us better support you by completing our online registration
today. You can register your device using one of two methods.
• Use the ActiveCaptain app.
WARNING
CAUTION
NOTICE
for help and information, such as
app.
www.garmin.com/support
operating system.
®
• Go to my.garmin.com/registration
account to register the device.
Keep the original sales receipt, or a photocopy, in a safe place.
After you add devices to the chartplotter network, register the
new devices.
Tools Needed
• Drill and drill bits
1
◦ 3.0 mm ( / in.) drill bit for bail mounting
8
9
◦ 14.6 mm ( / in.) drill bit for flush mounting
16
1
◦ 3.2 mm ( / in.) drill bit for flush mounting using wood
8
screws
9
◦ 3.6 mm ( / in.) drill bit for flush mounting using the nut
64
plate
1
◦ 6.0 mm ( / in.) drill bit for flush mounting using the nut
4
plate
• #2 Phillips screwdriver
• Jigsaw or rotary tool
• File and sandpaper
• Marine-grade sealant, approved for use on plastics
(recommended)
Mounting Considerations
This device should be mounted in a location that is not exposed
to extreme temperatures or conditions. The temperature range
for this device is listed in the product specifications. Extended
exposure to temperatures exceeding the specified temperature
range, in storage or operating conditions, may cause device
failure. Extreme-temperature-induced damage and related
consequences are not covered by the warranty.
You can flush mount the device in the dashboard, or bail mount
the device on the dashboard.
When selecting a mounting location, observe these
considerations.
• You should mount the device to provide an optimal viewing
angle as you operate your boat.
• You must select a location that is strong enough to support
the weight of the device and protect it from excessive
vibration or shock.
• To avoid interference with a magnetic compass, you must not
mount the device closer to a compass than the compass-safe
distance value listed in the product specifications.
• You must select a location that allows room for the routing
and connection of all cables.
• You should select a location that allows for easy access to
the device touchscreen.
• You should select a location that allows for access to the
microSD card in the back of the device. If the location does
®
not allow access, you must insert the memory cards before
installing the device.
Bail Mounting the Device
If you are mounting the bracket on fiberglass with screws, it is
recommended to use a countersink bit to drill a clearance
counterbore through only the top gel-coat layer. This will help to
avoid cracking in the gel-coat layer when the screws are
tightened.
You can use the bracket to bail mount the device on a flat
surface. The bracket and hardware are included in some
models.
and sign into your Garmin
NOTICE
NOTICE
March 2019
190-02469-02_0A
