7.2 Reflow soldering curve

8 E73 series

Model IC
E73-2G4M08S1C nRF52840
E73-2G4M04S1A nRF52810
E73-2G4M04S1D nRF51822
E73-2G4M04S1B nRF52832
Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co., Ltd
Tx
Frequency
power
Hz
dBm
2.4G 8
2.4G 4
2.4G 4
2.4G 4
Distance
Protocol
km
0.1 BLE 4.2/5.0
0.1 BLE 4.2/5.0
0.1 BLE 4.2
0.1 BLE 4.2/5.0
E73-2G4M08S1C User Manual
Size
Package
mm
SMD 13.0 * 18.0
SMD 17.5 * 28.7
SMD 17.5 * 28.7
SMD 17.5 * 28.7
Antenna
Ceramic
antenna/Sta
mp hole
PCB/IPX
PCB/IPX
PCB/IPX
