Installing ACP

Installing ACP
This chapter describes how to install the ACP to use.
In order to use the ACP, the installation should be performed by the following order.
STEP 1. Check the cautions during the ACP installation
Before installing the ACP, check the cautions.
STEP 2. Study the cable connections diagram of the entire system
Study the cable connection diagram of the site where the ACP is installed.
STEP 3. Set the indoor unit address
Set the address of the ACP not to be overlapped with the connecting indoor
unit.
STEP 4. Set PI485 and connect cables
Set DIP switch of PI485 correctly, and connect RS-485 communication
cable.
STEP 5. Install ACP and connect cables
Install the ACP, and set network and other settings.
STEP 6. Set ACP network address
Set the network address to be able to access the ACP through internet.
STEP 7. Set ACP functions
Set language, peak/demand, whether to use schedule, whether to use
power display, etc.
STEP 8. Set web GUI access environment
Set the access environment in web GUI, which is the operation program of
the ACP.
STEP 9. Input indoor unit and ventilator information
Set the access environment in web GUI, which is the operation program of
the ACP.
STEP 10. Verify and check ACP installation
Verify and check whether the ACP is properly installed.
CAUTION
!
Installing the ACP
• The ACP installation work needs the professional technique. Therefore, the installation
described in this chapter should be performed by the certified installation professional.
• Consult the service center or the professional installation agency certified by us about
any question or request related to the installation.
Installing ACP
5
