Summary of Contents for Krabat Pilot
- Page 1 Krabat Pilot Krabat Pilot User manual...
- Page 2 Safety All Krabat products are CE marked according to 93/42 / EØF, Class 1 of 14 June 1993 - Medical Device Directive. This certifi es that it meets all relevant European safety requirements. This manual is approved according to these standards. The shelf life of the product corresponds to a lifespan of about 5 years under normal use.
-
Page 3: Table Of Contents
Pilot Pilot Pilot General 01.0................s. Main components 02.0..........s. 03.0................... s. Adjustment/adaptation 04.0......s. Accessories 05.0..............s. Maintenance 06.0............... s. Warranty 07.0................s. - Page 4 Krabat Pilot...
-
Page 5: General
Krabat Pilot gives a dynamic assistance to lift the child pelvis and can be altered as the child is growing or changing their activity level. The height has infinite... -
Page 6: Main Components
02.0 Fig. 01 Main components Main components Krabat Pilot has the following main components: 01 Coat with integrated undercarriage 02 Mechanics 03 Main board with upholstery 04 Gas spring 05 Straps for groin and buttocks Krabat Pilot... -
Page 7: Use
03.0 Place the child in the prone position on the Krabat Pilot. Adjust the straps according to the child size and movement pattern. The strap around the buttocks can be adjusted using the plastic buckles on each side. It is important that this strap is not too tight. - Page 8 4 mm Allen key. Pull the board out to desired length and tighten. Screws for adjustment of the front board Screws for adjustment of the back board The front board can be set in to different positions, and the back board in three different positions Krabat Pilot...
- Page 9 Gas spring in position of the most lift Gas spring in position of medium lift Gas spring in position of light lift 04.4 Strap around buttocks The strap around buttocks has two plastic buckles which can be detached. Adjust the length by pulling the end of the strap. Plastic buckle to attach the strap around buttocks Adjustment of length Krabat Pilot...
-
Page 10: Accessories
The pads can be worn on top of normal clothing. Each set has got a left and a right pad which is connected to each other and the Pilot with elastic bands. This will assist the child in bringing the knees forward in alternate leg movements. -
Page 11: Maintenance
Back strap The back strap is available in one size only. It attaches to the Krabat Pilot in two premade slits. The back strap has one plastic buckle which can be detached. Adjust the length by pulling the end of the strap. -
Page 12: Warranty
KRABAT product, as it can harm both persons and the product as well as causing damage. VII Always – when not in use - store the KRABAT product in a safe manner in order for it not to be misused by anyone, and furthermore for the purpose of not exposing the KRABAT product to conditions that may harm it and/or its functions. - Page 13 KRABAT product carried out without the prior written consent from KRABAT. 10. This WARRANTY does not cover normal wear and tear. 11. KRABAT shall not under any circumstances be liable for defects in any part of a KRABAT product for more than two (2) years from delivery.
- Page 14 08.0 Notes Krabat Pilot...
- Page 16 KRABAT AS Ravnsborgveien 56, 1395 Hvalstad, NORWAY Telefon: +47 66 77 73 00 Fax: +47 66 77 73 01 www.krabat.com © Krabat, April 2017...
