Surface-Mounted NS Series Network Sensors with LCD (Part 2 of 2)
Humidity Sensor Type
Temperature Resolution
Temperature NS Series
Accuracy Network Zone
Sensor
Temperature
Element Only
Humidity NS-APx700x-0
Element Models
Accuracy
NS-AHx700x-0
Models
Time Constant
Default Temperature Setpoint
Adjustment Range
Ambient Operating
Conditions
Storage
Compliance BACnet
International
United States
Canada
Europe
Australia and
New Zealand
Dimensions
(Height x Width x Depth)
Shipping Weight
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local office. Johnson Controls, Inc. shall not be liable for damage resulting from misapplication or misuse of its
products.
European Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
Surface-Mounted NS Series Network Sensors with LCD Installation Instructions
Published in U.S.A.
Thin film capacitive sensor
±0.5F°/±0.5C°
±1.0F°/±0.6C°
0.35F° at 70°F (0.2C° at 21°C)
±2% RH for 20 to 80% RH;
±4% RH for 10 to 20% and 80 to 90% RH
±3% RH for 20 to 80% RH;
±6% RH for 10 to 20% and 80 to 90% RH
10 minutes nominal at 10 fpm airflow
50.0°F/10.0°C to 86.0°F/30.0°C in 0.5° increments
32 to 104°F (0 to 40°C); 10 to 90% RH, noncondensing;
85°F (29°C) maximum dew point
-4 to 140°F (-20 to 60°C); 5 to 95% RH, noncondensing
BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet Smart Sensor (B-SS)
Note: Excludes the NS-ATV700x-0 models.
UL Listed, File E107041, CCN PAZX,
Under UL 916, Energy Management Equipment
Note: Excludes the NS-ATA7001-0A and NS-ATA7002-0A models (Asia Only).
FCC Compliant to CFR 47, Part 15, Subpart B, Class A
UL Listed, File E107041, CCN PAZX7,
Under CAN/CSA C22.2 No. 205, Signal Equipment
Note: Excludes the NS-ATA7001-0A and NS-ATA7002-0A models (Asia Only).
Industry Canada, ICES-003
CE Mark – Johnson Controls, Inc. declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
RCM Mark, Australia/NZ Emissions Compliant
3-5/32 x 3-5/32 x 1-3/8 in.
(80 x 80 x 35 mm)
0.20 lb (0.09 kg)
NA/SA Single Point of Contact:
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2016 Johnson Controls, Inc.
