Microline condenser modular gooseneck microphone with 5-pin flush-mount power module

Advertisement

Quick Links

■ Introduction
Thank you for purchasing this product. Before using the product, read through
the user manual to ensure that you will use the product correctly. Please keep
this manual for future reference.
■ Features
• Modular microphone system comprised of an ES Series capsule, gooseneck
assembly, and power module.
• RGB LEDs built into both the flush-mount power module and gooseneck
assembly indicate the on/off status of the microphone.
• Includes external control function for device control from the capacitive touch
switch.
• The capacitive touch switch can be set to any of three operating modes:
"touch-on/touch-off", "touch-to-talk" and "touch-to-mute".

■ Safety precautions

Although this product was designed to be used safely, failing to use it correctly
may result in an accident. To ensure safety, observe all warnings and cautions
while using the product.
Cautions for the product
• Do not subject the product to strong impact to avoid malfunction.
• Do not disassemble, modify or attempt to repair the product.
• Do not handle the product with wet hands to avoid electric shock or injury.
• Do not store the product under direct sunlight, near heating devices or in a
hot, humid or dusty place.
WITH 5-PIN FLUSH-MOUNT POWER MODULE
■ Notes on use
• Check the strength of the mounting area. Insufficient strength or poor
mounting will cause objects to fall or become damaged.
• The circuitry in the microphone takes about 30 seconds to stabilize after power
is supplied. You may hear some audio disturbance during startup.
• Install the microphone on a flat, unobstructed mounting surface.
• Depending on the surface finish of a table, the isolators may leave marks on
the table.
• Do not excessively bend the gooseneck assembly, rotate the ends of the
capsule, or pull on them. Doing so may cause disconnection or malfunction.
• The product is a modular system comprised of a microphone element,
gooseneck assembly and power module. Make sure the parts are firmly
attached before use.
• Do not remove the rubber O-ring on the power module connecting part at the
lower section of the gooseneck assembly.
• When attaching parts, remove the black cap on the capsule connecting part
of the gooseneck assembly. Do not remove the silicone part at the end of
the capsule connecting part.
1
ES925ML6/FM5
ES925ML12/FM5
ES925ML15/FM5
ES925ML18/FM5
ES925ML21/FM5
ES925ML24/FM5

User Manual

MICROLINE CONDENSER
MODULAR GOOSENECK MICROPHONE
Silicone part
Do not remove
