- Page 1 ES947C/TB3 ES947WC/TB3 Cardioid Condenser Boundary Microphone User Manual English...
- Page 2 Safety precautions Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure safety, observe all warnings and cautions while using the product. Cautions for the product • Do not subject the product to strong impact to avoid malfunction. •...
- Page 3 Notes on use • Do not swing or carry the microphone by the cable to prevent the microphone from becoming disconnected or damaged. • Do not wind the cable around the rack or allow the cable to become pinched. • The microphone should be placed on a flat, unobstructed mounting surface. •...
- Page 4 Using the product Included accessories Rubber isolators 7.6 m (24.9') Microphone cable (TA3F, XLR-M)
- Page 5 Using the product How to mount the product Table/ceiling hole size (when using isolators) φ17 (Unit: mm) Table/ceiling hole size (when not using isolators) φ14.5 (Unit: mm) Example: Mounting on a table Front-of-mic indicator Rubber isolators Table...
- Page 6 Using the product Connection procedure The output connector is an XLR-M type with polarity as shown in the figure below. PIN1 (ground) PIN2 (hot) PIN3 (cold)
- Page 7 Dimensions φ20 M14P=1 (Unit: mm)
- Page 8 Specifications Element Fixed-charge back plate, permanently polarized condenser Polar pattern Cardioid Frequency response 70 to 15,000 Hz Open circuit sensitivity -38 dB (0 dB = 1 V/Pa, 1 kHz) Impedance 100 ohms Maximum input sound level 135 dB SPL (1 kHz at 1% THD) Dynamic range 110 dB (1 kHz at Max SPL) Signal-to-noise ratio...
- Page 9 Polar pattern/Frequency response Polar pattern 0˚ 330˚ 30˚ 60˚ 300˚ 270˚ 90˚ 120˚ 240˚ 150˚ 210˚ 180˚ LEGEND 200 Hz SCALE IS 1 kHz 5 DECIBELS PER DIVISION 5 kHz 8 kHz Frequency response 70 - 15,000 Hz 10 dB Frequency in Hertz LEGEND 0°, 50 cm...
- Page 10 株式会社オーディオテクニカ 〒194-8666 東京都町田市西成瀬2-46-1 www.audio-technica.co.jp Audio-Technica Corporation 2-46-1 Nishi-naruse, Machida, Tokyo 194-8666, Japan www.audio-technica.com ©2021 Audio-Technica Corporation Global Support Contact: www.at-globalsupport.com 142316911-02-01 ver.1 2021.02.01...
