Page 2: Document Control
All product, product specifications and data are subject to change without notice to improve reliability, function, design or otherwise. Kohler Uninterruptible Power has taken every precaution to produce an accurate, complete and easy to understand specification document and will assume no responsibility nor liability for direct, indirect or accidental personal or material damage due to any misinterpretation of, or accidental errors, in this manual. - Page 3 • All servicing must be performed by a qualified engineer approved by the manufacturer or its agent. Do not attempt to service the UPS yourself. • Kohler Uninterruptible Power will assume no responsibility or liability for accidents or injuries due to the incorrect operation or manipulation of the UPS or peripheral equipment.
- Page 4 Description AC Input power connector (IEC) Input fuse UPS Power outlets (4 x IEC) USB interface (standard) + RS232 interface (option) Modem/network surge protection (option) PW1000LT 650 / 1000VA Models Symbol Description ON: System malfunction Green ON: Line mode DIM: Abnormal input (V/Hz) Yellow ON: Battery mode Flashing: Battery Low...
-
Page 5: Installation And Setup
Description Line mode Input / battery voltage metering Input VAC VDC Min Output VAC Fault: UPS abnormal condition Alarm Output voltage metering Normal Backup Battery mode A.V.R. Load level (in 25% blocks) Automatic Voltage Regulation (AVR) mode Battery capacity (in 25% blocks) Figure 2.2 PW1000LT LCD Display Panel (option) Installation and set-up Unpacking the UPS equipment... -
Page 6: Maintenance
If required, connect the optional UPS communication ports to a local PC using a standard USB or 9-pin RS232 cable. Note: Appropriate communications software can be obtained from Kohler Uninterruptible Power. This concludes the installation. You can now turn ON the UPS as described in the Operating Instructions below. -
Page 7: Battery Replacement
WARNING: If you remove a cover from the UPS case you will be exposed to potentially lethal voltages. • The battery replacement procedure must be carried out by an electrically trained technician. • If a battery is faulty ALWAYS seek assistance from Kohler Uninterruptible Power or one of its local service agents. -
Page 8: Battery Disposal
1500/2200VA Model only (Fig D) Using an insulated screwdriver, remove the two screws from the battery holding plate. 10. Loosen and disconnect the cable from the battery negative terminal followed by the red battery positive terminal. 11. Loosen and remove the link connecting the two batteries together (shown in green in the diagram) 12. -
Page 9: Specification
Specification PW1000/ 800LT PW1000/ 1500LT PW1000/ 2200LT Capacity 800VA 1500VA 2200VA Input Voltage 220/230/240 VAC Voltage range 160~290 VAC Output Voltage regulation ±10% Transfer time Typical 2-6ms, 10ms max. Waveform Simulated sinewave Battery Type and number 12V/9Ah x 1 12V/9Ah x 2 Charging time 4-6 hours recover to 90% capacity Physical...
