Summary of Contents for Bissell 5200
-
Page 1: Table Of Contents
1 ug603_6719_5200E_305.indd 1 U S E R ’ S G U I D E 5200 Series 220-240V Thanks Consumer Services Safety Instructions Product View Features / Assembly Operation Clean-Up / Storage Troubleshooting Replacement Parts About Your Warranty 9-10 11/16/05 2:58:43 PM... -
Page 2: Thanks
Department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your Flip-It. - Page 3 Telephone: 01-616-453-4451 Fax: 01-616-453-1383 Or visit the BISSELL website - www.bissell.com When contacting BISSELL, have model number of unit available. Please record your Model Number: ___________________ Please record your Purchase Date: ___________________ NOTE: Please keep your original sales receipt. It provides proof of date of purchase in the event of a warranty claim.
-
Page 4: Important Safety Instructions
■ Do not unplug by pulling on cord. Unplug by grasping plug. ■ Use only manufacturer’s recommended attachments. ■ Use only cleaning products formulated by BISSELL for use in this appliance to prevent internal component damage. See Cleaning Formula Section of the User's Guide. ug603_6719_5200E_305.indd 4 ug603_6719_5200E_305.indd 4 ■... -
Page 5: Product View
Product View Wet Vacuum Suction Path CAUTION: depressing the Spray Trigger on the forward stroke only and release the Spray Trigger on the rearward stroke. Over wetting the floor surface may cause delamination of certain laminated flooring materials. ug603_6719_5200E_305.indd 5 ug603_6719_5200E_305.indd 5 Spray Trigger... -
Page 6: Putting It Together
The Pleated Filter, located in the lid of the Dirty Tank should be cleaned periodically. Putting It Together Assembling your new BISSELL Flip-It is a simple 2 Step Process: NOTE: Remove Clean Tank from unit first. Insert the Handle into the top of the unit, making sure the Spray Trigger is on the Wet Vacuum side. - Page 7 Unscrew the black Cap on the bottom of the Clean Tank and remove the Insert. Filling the Clean Tank: Fill with BISSELL Formula to the Formula fill line and fill with water to the Water line. Replace the Insert and Cap Assembly. Place the full Tank back into the unit.
-
Page 8: Dry Vacuuming
Dry Vacuuming With the Dry Vacuum Side of the unit facing forward, turn the unit on and begin cleaning. You will see dry dirt, crumbs and debris being collected in the Dirty Tank. You do not have to empty the dry debris before Wet Cleaning. Flipping from Dry to Wet Cleaning To change from Dry Vacuuming, to Wet Cleaning simply flip the unit around to the Wet Vacuum side! - Page 9 Dirty Tank Is Full While Wet Cleaning, you will see dirty water collected in the Dirty Tank. When the Tank is full, the white Float in the Dirty Tank will rise to the top, making a noticeable sound to let you know it is time to empty the Dirty Tank. When You're Finished Emptying the Dirty Tank Remove the Dirty Tank Lid.
-
Page 10: Troubleshooting
Storing The Flip-It Your Flip-It can be stored Ready-to-Use, by leaving water and Formula in the unit. Be sure to remove wet Gentle Clean™ Pad before storing. Troubleshooting Water & Formula are draining out from the Clean Tank Possible Causes Clean Tank black Cap &... -
Page 11: Replacement Parts
Replacement Parts Item Part No. 203-6705 203-6706 203-6707 203-6708 203-6725 203-6711 203-6713 203-6714 203-6700 203-6701 203-6702 3270 0482 0484 ug603_6719_5200E_305.indd 11 ug603_6719_5200E_305.indd 11 Part Name Pleated Filter Dirty Tank Lid Assembly Dirty Tank Wet Cleaning Nozzle Clean Tank with Cap and Insert Handle with Screw -Acier Cap and Insert Assembly Cord Wrap - Acier... -
Page 12: About Your Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for two years any defective or malfunctioning part do to manufactures defect.
