WARNING
This manual describes important points of caution for safe use of this product in potentially explosive atmosphere. Please
read this manual carefully before installing and operating the product.
The DOL 46R capacitive relay sensor series is designed for general
detection of feed, grain and solids. Certified according to ATEX directive
2014/34/EU and IECEx for operation in potential explosive dust
atmospheres. Classified as equipment for use in atmospheres with
continuous presence of explosive dust with an ignition temperature above
o
85
C.
Robust design with plastic housing with 7 joule shock/impact test. Available
with trimmer interface with adjustable sensing distance, time delay and
MaxRunTimer.
For other language variants of
this document we refer to
sensors.com
or your local dealer.
dol-sensors a/s
Hedelund 4, Glyngøre
www.dol-
7870 Roslev
Denmark
DOL 46R
Capacitive Sensors
ATEX zone 20, 21 and 22, dust
II 1D Ex ta IIIC T
Tlf. +45 72 17 58 88
Fax +45 72 17 59 59
TECHNICAL USER'S GUIDE
CE
o
85
C Da
200
www.dol-sensors.com
EN
0539
Advertisement
Table of Contents
Related Manuals for DOL 46R
Summary of Contents for DOL 46R
- Page 1 0539 II 1D Ex ta IIIC T C Da The DOL 46R capacitive relay sensor series is designed for general detection of feed, grain and solids. Certified according to ATEX directive 2014/34/EU and IECEx for operation in potential explosive dust atmospheres.
- Page 2 Temp. storage: - 40 °C - + 80 °C MOUNTING GUIDE (FIG. 1): - 40 °F - + 176 °F DOL 46R is made in a ø30 mm smooth Relay NC (1-4) Degree of protection: design mounted in a gland.
- Page 3 If the user reduces the sensitivity to almost minimum, the sensor will not be able to detect objects in front of it. In this fail situation, the internal relay will always be ON but the temperature class 85 C will never be exceeded. dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf.
- Page 4 Permissible operating temperature of the application (proper usage): Ta: -30°C...+50°C MAINTENANCE / REPAIR The unit must not be modified nor can it be repaired. In case of a fault please contact the manufacturer. dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf.
