Linkam Scientific Instruments RH95 User Manual

Humidity controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Linkam Scientific Instruments
RH95 Humidity Controller
1.1.1
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RH95 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Linkam Scientific Instruments RH95

Summary of Contents for Linkam Scientific Instruments RH95

  • Page 1 Linkam Scientific Instruments RH95 Humidity Controller 1.1.1 USER GUIDE...

  • Page 2: Table Of Contents

    ................................... 8 Air Inlet Connector ................................... 8 Connecting the RH95 to the humidity chamber ......................................9 ......................................10 Connecting the RH95 to a Linkam Heating Stage Using the RH95 Controller ...................................12 Filling the water bottle ........................................12 Desiccant conditioning ........................................14 Setting the humidity level ........................................

  • Page 3: Introduction

    Thank you for purchasing your Linkam equipment, please take a moment to read this manual before setting up the equipment. If you have purchased control software, please install the software first. See your software manual for further installation instructions. v1.1.1 © 2017 Linkam Scientific Instruments Ltd.

  • Page 4: Important Notices

    Any technical questions or queries should be addressed to the Technical Support Department at the address shown below and on the back of this manual. Tel: +44(0)1737 363 476 Email: support@linkam.co.uk Feedback Your feedback will be greatly appreciated, please email us directly info@linkam.co.uk v1.1.1 © 2017 Linkam Scientific Instruments Ltd.

  • Page 5: Safety Information

    RH95 unit. Contact Linkam Scientific Instruments Ltd or their appointed distributor immediately. Your warranty may be impaired if Linkam is not informed of any transport damage within 7 working days of delivery.

  • Page 6: Informations De Sécurité

    à l'alimentation ou à l'unité RH95 Contactez Linkam Scientific Instruments Ltd ou son distributeur désigné immédiatement. Votre garantie pourrait être réduite si Linkam n'est pas informée de tout dommage causé par le transport dans les 7ouvrables suivant la livraison.

  • Page 7: System Overview

    System Overview The RH95 system contains the following components: RH95 Controller RH95 power adaptor Mains lead Humidity sensor and cable for humidity chamber Humidity chamber Humidity chamber tool RH water bottle Humidity data RS232 cable (only included when a T95 controller is supplied)

  • Page 8: Connecting Your Rh95 Controller

    Air Inlet Connector This is the port that supplies air to the RH95 controller for humidification / drying. Blocking access to this port will prevent the RH95 from functioning. Important Note: Only suitable for use with gas at atmospheric pressure. DO NOT flow pressurized gas into this port.

  • Page 9: Connecting The Rh95 To The Humidity Chamber

    Connecting the RH95 to the humidity chamber Your RH95 system includes a small humidity chamber that can be used to test your samples at ambient temperature. To connect the RH95 controller to the supplied humidity chamber follow the below procedure: Note: This chamber is also used when validating the humidity reading.

  • Page 10: Connecting The Rh95 To A Linkam Heating Stage

    Connecting the RH95 to a Linkam Heating Stage If you have purchased a Linkam heating stage with humidity capability to go with your RH95 controller, follow these instructions to connect it: IMPORTANT NOTICE: The humidity sensor is extremely sensitive to contaminants - DO NOT touch the exposed chip or allow anything to come into contact with it.
  • Page 11 Connect the humidity tube from the front of the RH95 to the port on the Linkam stage, as shown: Insert the gas valve insert into the gas valve on the opposing side of the stage to the humidity feed. You are now ready to control the humidity of your Linkam stage.

  • Page 12: Using The Rh95 Controller

    This section describes the operation of the RH95 control unit. Filling the water bottle Before the RH95 can control the humidity of your sample chamber, the water bottle must be filled. It is important that only distilled water is used in the Humidity Generator.
  • Page 13 Replace the magnetic front panel of the RH95 Important Note: Before shipping the RH95, the water bottle should be removed from the unit, drained and placed into the space provided in the packaging. The RH95 should not be shipped with the water bottle fitted.

  • Page 14: Desiccant Conditioning

    Setting the humidity level Tap on the humidity value on the LCD display of the RH95 controller. This will bring up a number pad. Enter a humidity value of between 10-90% and press Ent. Press C to clear the last digit.

  • Page 15: Rh95 Settings And Configuration

    This includes the chamber type it is designed for and the serial number of the sensor. Touchscreen Calibration If the touchscreen interface on the RH95 is not responding correctly to touch input, it may need to be re-calibrated. In order to do this, please follow this procedure: Power down the RH95 Controller.

  • Page 16: Validating The Humidity Reading

    Validating the humidity reading If you have purchased an optional Rotronic calibration standard with your RH95 unit, you can use these to validate the humidity reading of your RH95. You should have received the following package: This will contain some textile pads and five ampoules of calibration salts. The RH% will depend upon which kit was ordered. They are available in RH values of 10%, 35%, 65% and 80%.
  • Page 17 Note: Be careful during this step to make sure the RH sensor does not come into contact with the soaked pad. The salts will damage the sensor if it comes into contact with them. v1.1.1 © 2017 Linkam Scientific Instruments Ltd.
  • Page 18 Replace the lid of the humidity chamber and place the caps on the white plastic air ports. Allow the chamber to reach humidity equilibrium (see table below) and switch the RH95 unit on. You can now compare the humidity reading of the RH95 with the expected humidity value of the calibration standard used to validate the accuracy of the RH95.

  • Page 19: Declaration Of Conformity

    Low Voltage Directive 2014/35/EU using product standard EN 61010-1:2010 RoHS 2 Directive 2011/65/EU and also carries the additional certification: EMC: FCC CFR 47 Part 15B:2014 Safety: IEC 61010-1:2010/EN 61010-1:2010/UL 60950-1:2012/CAN/CSA no. 61010-1-12 Date: 14th April 2016 R&D Manager: Peter Grocutt v1.1.1 © 2017 Linkam Scientific Instruments Ltd.

  • Page 20: Technical Specifications

    Micro USB Type B connector: Currently only used for firmware updates. Power Supply Supply Voltage: 24Vdc Minimum Supply Current: Connector: 4 pin Mini DIN Note—only use an earth referenced power supply with this equipment v1.1.1 © 2017 Linkam Scientific Instruments Ltd.
  • Page 21 © 2017 Linkam Scientific Instruments Ltd.
  • Page 22 Linkam Scientific Instruments Ltd Tel: +44(0)1737 363 476 Fax: +44(0)1737 363 480 Email: support@linkam.co.uk Unit 8 Epsom Downs Metro Centre Waterfield, Tadworth, Surrey, KT20 5LR, UK www.linkam.co.uk...
