  • Page 1 Linkam Scientific Instruments LTSE420-P Temperature Controlled Probe Stage USER GUIDE...

  • Page 2: Table Of Contents

    Warranty..........................4 Technical Support.........................4 Equipment Maintenance......................4 Handling Liquid Nitrogen.......................4 Feedback..........................4 Safety Precautions........................5 Symbol Reference.....................5 Introduction..........................6 LTSE420-P Stage Specification...................6 LTSE420-P System........................6 Stage Anatomy........................7 Lid Assembly......................7 Stage and Heater Assembly…………………………………………………………..…………..………….7 Stage Connectors Assembly…………………….…….…………………...…………………………………..7 LTSE420-PL8 Stage Assembly..................8 LTSE420-PB4 Stage Assembly..................8 Mounting Stage to Microscope with Dovetail Substage.............9 Setting up the Condenser......................9...

  • Page 3: Before Setting Up Your Equipment

    Before Setting Up Your Equipment Please register your products by going to www.linkam.co.uk and click on the product/software registration button. You will need to register your equipment with us to:  Activate your warranty and technical support  Access the online setup videos ...

  • Page 4: Important Notice

    Important Notice Please check that your Linkam equipment has not been damaged during transit. If there is any evidence of external damage DO NOT SWITCH ON ANY ELECTRICAL ITEMS. Contact LINKAM SCIENTIFIC or their appointed distributor immediately. Your warranty may be im- paired if Linkam is not informed of any transport damage within 7 working days of delivery.

  • Page 5: Safety Precautions

    Safety Precautions Safety Precautions Read this guide before using the equipment. Save these instructions for later use. Follow all warnings and instructions which may be placed on the stage. Never use the equipment if any cables have been damaged. Do not allow any heavy objects to rest on the cables.

  • Page 6: Introduction

    Maximum voltage: 300V AC Maximum ampere: LTS420-P System with LNP95 LTSE420-P System There are two versions of the LTSE420-P stage: 1. LTS420-PL8 2. LTS420-PB4 The LTSE420-PL8 stage is supplied with 2x 4 pin Lemo connectors and the LTSE420-PB4 stage is supplied with 4x BNC connectors.

  • Page 7: Stage Anatomy

    Stage Anatomy Lid Assembly Swing the Stage Lid (1) to open the Stage. 1. Stage Lid 2. Lid Insert 3. Viewing Window 4. Hinge 5. Holes for Tube Clip Holder or window removal tool Swing Stage Lid to open Stage and Heater Assembly 6.

  • Page 8: Ltse420-Pl8 Stage Assembly

    LTSE420-PL8 Stage Assembly 1. Probe 2. Electrical contact 3. Metal base plate 4. 4 Pins Lemo connector LTSE420-PB4 Stage Assembly 4. Probe 5. BNC Connector 6. Metal base plate...

  • Page 9: Mounting Stage To Microscope With Dovetail Substage

    Mounting Stage to Microscope with Dovetail Substage The following description is for mounting the stage on to microscopes which have a circular 9542 curved clamps set dovetail substage assembly (1). Attach the curved stage clamps (part no. 9548) to the base of the stage using the supplied hex screws and the outer most holes in the base plate.

  • Page 10: Setting Up Ecp Water Circulator Pump

    Setting up ECP Water Circulator Pump If you have purchased the ECP with your LTSE420-P stage, read the following to set up the ECP (1). Refer to the ECP manual for more details. When heating the stage above 300°C for a pro- long period of time, the metal body of the stage can get quite hot.

  • Page 11: Connecting The Instruments

    Connecting the Instruments T95 System Controller Cable Connections T95 back panel For more details on the T95 System Controller please refer to the T95 System Controller manual. Connect the Stage Cable to the Lemo Connector on the stage and connect the other end to the Stage Connection Socket (1).

  • Page 12: Ltse420-Pb4 Bnc Wire Connection

    Only read the following section if you have the LTS420-PB4 stage with the BNC connector. Remove the Probe The LTSE420-P is supplied with 4 tungsten gold plated tip Probes inside the stage. The probe assembly (1) has a magnetic base and is held in place by the metal plate (2) inside the stage cham- ber .
  • Page 13 Wire your BNC cable to the supplied BNC plug. Plug the BNC plug into the BNC Socket.

  • Page 14: Ltse420-Pl8 Lemo Wire Connection

    LTSE420-PL8 Lemo Wire Connection Only read the following section if you have the LTS420-PL8 stage supplied with the Lemo con- nectors. Remove the Probe The LTSE420-PL8 is supplied with 4 tungsten gold plated tip Probes inside the stage. The probe assembly (1) has a magnetic base and is held in place by the metal plate (2) inside the stage cham- ber .
  • Page 15 The 8x internal electrical contacts are wired to 2x external 4 pin Lemo conectors (1) Wire cables to your supplied Lemo connector. To reconnect the Lemo, line up the red dot on the Lemo plug (2) to the red tab on the Lemo socket (3) and push the Lemo firmly into place.

  • Page 16: Adjusting The Probe

    Adjusting the Probe Probe orientation: The probe has a magnetic base (3) and can be placed in any orientation inside the LTSE420-P stage using the metal base plate. Note: be extra careful when placing the Probe near to the PT100 platinum temperature sensor (4), the PT100 is very fragile and can be easily be damaged.

  • Page 17: Change The Angle Of The Needle

    Adjust the length of the needle: Pull end of the needle to the desired length and use a wire cutter to cut the needle shorter. Bend the tip of the needle: Use a pair of flat pliers to bend the tip of the needle.

  • Page 18: Sample Preparation

    Sample Preparation For accurate results it is most important that the surface of the block is extremely clean, since air gaps between the heating block and the sample will result in temperature errors. Use a soft cloth and IPA (iso-propyl alcohol) to clean.
  • Page 19 Or place a standard microscope glass slide (26 x76mm) on top first and then place your sample on top of the microscope glass slide. Arrange the Probes around your sample as re- quired by your experiment. Note: make sure the yellow wires are not touching the silver block.

  • Page 20: Cooling Connections

    Cooling Connections These connections need only be made if the experiments are to be carried out below room temperature. The Dewar siphon (1) is the thick white foam tubing and is attached to the liquid nitrogen Dew- ar. The thin black capillary tube inside the white foam tube must be inserted into the liquid nitro- gen cooling connector on the stage.

  • Page 21: Purging Procedure

    Purging Procedure Before starting a cooling experiment, you will need to purge air from the stage chamber with dry nitrogen. This will remove the water in the air which would otherwise condense and freeze on the sample disrupting your image quality. Before you can start purging, the LNP95 must be set to manual mode.

  • Page 22: Purging The Stage Method 1

    Purging the Stage Method 1 There are two methods for purging the stage. Method 1 uses recycled nitrogen gas produced by the LNP95 from the 2L Dewar. Make sure the stage lid is in place and the stage door is closed. Switch on the temperature programmer and set the limit to 40°C.

  • Page 23: Purging The Stage Method 2

    Purging the Stage Method 2 This method uses an inert gas from a gas cylinder to purge the stage at temperatures above ambient when the LNP95 is not required. 1. Make sure the Stage Lid is in place and the Stage Door is closed.

  • Page 24: Appendix

    Appendix Window Assembly Lid Window Assembly To replace the windows in the Stage Lid (1) use the Window Tool (2) and align the two wide spacing pins to the Tube Clip Holder holes and unscrew the Lid Insert (3). The Stage Lid and Lid Insert should be turned upside down as shown in the diagram opposite and reassembled in the order indicated.

  • Page 25: Use Linkpad To Set The Lnp95 To Manual Mode

    Troubleshooting Cooling fault diagnosis Ensure that all connections to the stage and Dewar are as described in the specific manual and that the stage lid and top windows are properly sealed. 1. The cooling rate is less than programmed. There can be several causes of this problem, the most likely being that one of the connectors has become blocked or damaged.

  • Page 26: Contact Details

    Linkam Scientific Instruments Ltd Tel: +44(0)1737 363 476 Fx: +44(0)1737 363 480 info@linkam.co.uk Unit 8 Epsom Downs Metro Centre Tadworth, Surrey, KT20 5LR, UK www.linkam.co.uk Ver:1.02.032010...
