Specifications

AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into 4 ohms,
4 channels driven from 20 Hz to 20 kHz with no more than 5% total
harmonic distortion.
CD Player section
Signal-to-noise ratio
Frequency response
Wow and flutter
Tuner section
FM
Tuning range
Antenna terminal
Intermediate frequency
Usable sensitivity
Selectivity
Signal-to-noise ratio
Harmonic distortion at 1 kHz
Separation
Frequency response
AM
Tuning range
Antenna terminal
Intermediate frequency
Sensitivity
Power amplifier section
Outputs
Speaker impedance
Maximum power output
General
Outputs
Inputs
Tone controls
24
90 dB
10 – 20,000 Hz
Below measurable limit
87.5 – 107.9 MHz
External antenna connector
10.7 MHz/450 kHz
9 dBf
75 dB at 400 kHz
67 dB (stereo),
69 dB (mono)
0.5 % (stereo),
0.3 % (mono)
35 dB at 1 kHz
30 – 15,000 Hz
530 – 1,710 kHz
External antenna connector
10.7 MHz/450 kHz
30 µV
Speaker outputs
(sure seal connectors)
4 – 8 ohms
52 W × 4 (at 4 ohms)
Audio outputs (front/rear)
Power antenna relay control
terminal
Power amplifier control
terminal
Telephone ATT control
terminal
Remote controller input
terminal
BUS control input terminal
BUS audio input terminal
Antenna input terminal
Low:
±10 dB at 60 Hz (XPLOD)
Mid:
±10 dB at 1 kHz (XPLOD)
High:
±10 dB at 10 kHz (XPLOD)
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Optional accessories
Optional equipment
Note
This unit cannot be connected to a digital preamplifier
or an equalizer which is Sony BUS system compatible.
Design and specifications are subject to change
without notice.
12 V DC car battery
(negative ground)
Approx. 178 × 50 × 180 mm
× 2 × 7
1 1
(7 / / in)
8 8
(w/h/d)
Approx. 182 × 53 × 161 mm
× 2 × 6
1 1 3
(7 / / / in)
4 8 8
(w/h/d)
Approx. 1.2 kg
(2 lb 10 oz)
Card remote commander
RM-X115
Parts for installation and
connections
Front panel case (1)
Rotary commander
RM-X4S
CD changer (10 discs)
CDX-757MX, CDX-656
CD changer (6 discs)
CDX-T70MX, CDX-T69
MD changer (6 discs)
MDX-66XLP
MG-MS System-up Player
MGS-X1
XM Satellite Radio
Receiver
XT-XM1
Source selector
XA-C30
AUX-IN Selector
XA-300
