- Page 1 LED Moving Head Light MJ-1006C User Manual Thank you for choosing our LED moving head light. For the sake of your safety, Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Catalogue Chapter Safe Usage Of The Product --------------------------------------------------------------------------3 Preliminary Specifications ----------------------------------------------------------------------------4 Install The Equipment ---------------------------------------------------------------------------------4 Power Code Connection ------------------------------------------------------------------------------5 DMX Connection ---------------------------------------------------------------------------------------5 DMX Terminator ----------------------------------------------------------------------------------------6 Function Set -----------------------------------------------------------------------------------------------7 Operation Menu ------------------------------------------------------------------------------------------7... -
Page 3: Safe Usage Of The Product
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 SAFE USAGE OF THE PRODUCT When unpacking and before disposing of the carton, check there is no transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. -
Page 4: Preliminary Specifications
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 The MJ10064in1 unlocks a new dimension in colour control with it's unique six cell arrangement opening up a whole new level of creative potential within. The MJ10064in1 primary lens array can be changed with an optional lens kit allowing different beam angles to suit your projection requirements. -
Page 5: Power Code Connection
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Use 1pcs clamp and safety cord(need to purchase).Use clamp fix with light hook which in the packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure and fasten the screws attached to each clamp. -
Page 6: Dmx Terminator
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and sockets. -
Page 7: Function Set
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Function Set: MENU DOWN UP ENTER Use button switch and LCD display, can set the address code and function code easily. Check or modify lighting function settings, Press ENTER button, LCD display panel will display function menu of lighting. - Page 8 LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Option Set Pan Invert Pan swap off Pan swap off Tilt Invert Tilt swap off Tilt swap on Dimmer Invert Dimmer swap off Dimmer swap on Display Set Language Set English...
-
Page 9: Menu Operation Instructions
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Reset To Factory Mode Sytem Reset Menu Operation Instructions： 一： DMX512 Address code Settings： 1. Press “MENU” button to Set DMX Address，to confirm by press “ENTER” button。 2. Show Set DMX address DMX address:001， correct by pressing “UP&DOWN” button。... -
Page 10: Maintenance
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 六：Information 1. Press “MENU” button to information confirm by press “ENTER” button. It will show Power On Hours, Power this time ,Head Sensor, Software Version. 2. Press “ENTER” button to save and quit. Press “MENU” button to quit no saving. -
Page 11: Equipment And Appendix
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Equipment and Appendix: The packing list of this light as follows: ☆ Led moving head light 1pcs ☆ Power Cable 1pcs ☆ Signal Cable 1pcs ☆ Light Hook 1pcs ☆ M10 Screw 2pcs ☆... - Page 12 LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 XY speed 0~255 0~255 Main Strobe 0~255 Main dimming A segment 0~255 Strobe A segment dimming 0~255 CH10 0~255 A segment Red CH11 0~255 A segment Green CH12 0~255 A segment Blue...
-
Page 13: Technical Parameters
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Technical Parameters: Construction: Composite plastic, die-casting aluminum, Voltage: AC90V-240V; 50/60Hz Power Consumption: 400W @(220V) LED Bulbs:4in1*36LEDs LED Current: 500mA LED Lifetime: 50000Hours Colors: RGBW color mixing Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also...
