- Page 1 4000 Bordentown Avenue, Suite 16 Sayreville, NJ 08872 Phone: 732-238-0096 — Toll Free 1-800-224-1717 — Fax: 732-238-4404 www.cranemachines.com Lucky Zone...
-
Page 3: Table Of Contents
Contents 1、Important Information ······················································· 1 2、Introduction ··································································· 1 3、Accessories···································································· 3 4、Playing introduction ························································· 4 5、Warnings ······································································ 5 6、Operation instruction ························································ 6 6-1、Lottery installation instruction ····································· 6 6-2、Methods of releasing from no lottries alarm ····················· 7 6-3、Moving instruction ·················································· 7 7、Configuration ································································· 8 7-1、The Configuration for the whole equipment ·····················... -
Page 4: 1、Important Information
To avoid electrical Shock, turn off and unplug the game power before servicing. Please read this manual carefully before operating. 2、 、 、 、 Introduction LUCKY ZONE is a fast coin amusement game. It is simple to play for all ages. The... - Page 5 game is setup for coins/tokens in and tickets out.. There are two attractive bonuses which will keep the player's interests.
-
Page 6: 3、Accessories
3、 、 、 、 Accessories Please check all the following accessories are ready or not before moving Fitting Fitting Fitting Fitting Spec Spec Quantity ntity Sketch Sketch map Remarks Remarks Spec Spec ntity ntity Sketch Sketch Remarks Remarks name name name name Setting according... -
Page 7: 4、Playing Introduction
4、 、 、 、 Playing introduction Insert a coin/token, and the coin/token will drop onto the flat through Top Funnel Part. The coin/token will drops into a random hole, and the corresponding LED will light up; and corresponding values will be paid in tickets according to the hole value displayed on the hole. -
Page 8: 5、Warnings
5、 、 、 、 Notice The power cord must removed and unplugged before moving this machine. Please comply with manufacture’s requirements during the process of moving and transportation. The equipment should be setup on a even floor. Please do not lay any sundries on the equipment. The power supply should not be pressed by heavy object, and the circuit should not be uncovered for a long time. -
Page 9: 6、Operation Instruction
6、 、 、 、 Operation introduction 6-1、 、 、 、 Lottery-installing introduction. Open the lottery door by the key Put the lotteries in the lottery box with face upside. Put the lottery in leading slot, and drive it below the holding wheel. Press the jiggle switch in the lottery machine’s PCB by hand, until the first lottery is sent out. -
Page 10: Methods Of Releasing From No Lottries Alarm
6-2、 、 、 、 Methods of releasing from no lottery alarm If there is no lottery in the box or error when outputting the lottery, the machine will alarm automatically, and the methods of releasing from alarm are bellowing: (一 一 一 一 )、 、 、 、 Press the error releasing button on the code list to release from alarm. (二... -
Page 11: 7、Configuration
7、 、 、 、 Configuration 7-1、 、 、 、 The whole equipment configuration Digital display Coins inserting machine Top Funnel Part Stainless steel columns Coins rolling plate 滑币盘 here Coins drop from （币由此落入各孔位） Large turntable Holes 以文字图案显示 Determine the lotteries or 确... - Page 12 1、coins-inserting machine CPU comparison coins-inserting machine： ： ： ： Advisable coins diameter：Ф22mm～Ф28mm Advisable coins thickness:1.5mm～2.0mm Working voltage：DC+12V±20% Working temperature ：0℃～+50℃ Coins folder Sample coins 人民币专用 For using real coins using sample Coins inserting door low accuracy acy adjustment High accuracy Gary line Coins inserting hole Red DC+12V...
- Page 13 (二 二 二 二 )、 、 、 、 Choose to use real coins or sample cost, please adjust SW3 (三 三 三 三 )、 、 、 、 Please adjust SW2 to choose the inserting signal speed. (四 四 四 四 )、 、 、 、 Please adjust the sensitivity of filtering coins, please spin the accuracy adjustment to adjust；...
-
Page 14: 8、Analyse For Familiar Malfunction
8、 、 、 、 Analyses for familiar error Malfunction Causes Causes Resolution Resolution Causes Causes Resolution Resolution description 1、Turn on the power,；change the 1、Power is off or fuse is broken fuse 2、Switch power supply box is broken Do not work 2、Change switch power supply box 3、CPU board is broken 3、change CPU board... -
Page 15: 9、Dail Code List
（ （ （ （ Table 2） ） ） ） 9、 、 、 、 Dial Code Setting Usage Usage Code group Lottery out（Please dial the code on KNW3.6 ） （For lottery mode） No lottery out（Please dial the code on KNW3.6） （For lottery mode） Clear electric-protect parameter （Please dial the code on KNW3.6）... -
Page 16: 10、Resource Allocation List
1 light win when Winning “?”bonus （Can be adjusted by dial code on small PCB） 2 lights win when Winning “?”bonus （Can be adjusted by dial code on small PCB） 3 lights win when Winning “?”bonus OFF OFF （Can be adjusted by dial code on small PCB）... - Page 17 IN24 IN25 IN26 IN27 IN28 IN29 IN30 Hardware Test button Replenish switch for No lottery alarm(if IN31 error happens, press this button to go on) 5V Power supply positive port Power supply negative port JP13 JP13 JP13 JP13 Power supply negative port +12V 12V Power supply positive port Left CH positive port...
- Page 18 Ｏ20 Ｏ Ｏ21 Ｏ Ｏ22 Ｏ Ｏ23 Ｏ Effect LED 1 besides the door（See from Ｏ24 Ｏ front of the machine, from up to down, with both sides paralleled） Effect LED 2 besides the door（See from Ｏ25 Ｏ front of the machine, from up to down, with both sides paralleled）...
- Page 19 IN11 35 lotteries refraction Test IN12 25 lotteries refraction Test 12 IN13 8 lotteries refraction Test IN14 5 coins refraction Test IN15 7 lotteries refraction Test IN16 50 lotteries refraction Test IN17 20 lotteries refraction Test IN18 18 lotteries refraction Test IN19 16 lotteries refraction Test INPUT3...
- Page 20 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Ｏ20 Ｏ 40 lotteries LED drive signal Ｏ21 Ｏ Lucky LED drive signal Ｏ22 Ｏ 2 coins LED drive signal Ｏ23 Ｏ 13 coins LED drive signal Ｏ24 Ｏ...
