HIGH-PERFORMANCE VIDEO
BORESCOPE SYSTEM
WITH 4.9mm SWITCHABLE
FRONT/SIDE VIEW
FLEXIBLE-OBEDIENT PROBE
USER'S MANUAL
DCS11
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
Please read this manual carefully and thoroughly before using this product.
Advertisement
Table of Contents
Related Manuals for General DCS1100
Summary of Contents for General DCS1100
- Page 1 HIGH-PERFORMANCE VIDEO BORESCOPE SYSTEM WITH 4.9mm SWITCHABLE FRONT/SIDE VIEW FLEXIBLE-OBEDIENT PROBE USER’S MANUAL DCS11 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Please read this manual carefully and thoroughly before using this product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ....... 3 Key Features....... 4 Safety Instructions . -
Page 3: Introduction
The DCS1100 offers a cost-effective way for technicians, mechanics, contractors and repairmen to visually inspect inaccessible or hazardous areas and thus diagnose hidden system problems without the need for a complete disassembly or teardown. -
Page 4: Key Features
Also remember that the probes are not electrically insulated, so never bring them into contact with exposed AC wiring. The DCS1100 is intended for industrial use only. Do not use it for human or any other biological inspections. -
Page 5: Product Overview
PRODUCT OVERVIEW Figure 1 shows the key components of the DCS1100 handle, shown attached to a generic camera probe. µ ³ ¸ ³ · (POWER) button ¾ · 2.4 in. (diagonal) LCD » Brightness Up button » ² ¿ Power on light ¿... -
Page 6: Setup Instructions
P1618FS-49 probe. VIEW ³ SIDE VIEW · » ³ To probe socket on DCS1100 handle · View indicator lights » View switch 2. The P1618FS-49’s controls, indicators and other physical features SETUP INSTRUCTIONS INSTALL 4 BATTERIES To open the battery compartment (on... -
Page 7: Attaching An Optional
NORMAL OPERATION To use the DCS1100, point the camera end of the probe at the area or object of interest. Live video will appear on the display. To change the view of the front/side view probe, toggle the view switch (see Figure 2). - Page 8 AV out jack (labeled “TV”) on the top of the DCS1100. Plug either the yellow or white RCA plug at the other end of the cable into the “Video In” jack of your TV or monitor. The video will appear both on the TV or computer monitor and on the DCS1100’s display.
-
Page 9: Specifications
SPECIFICATIONS Handle Display Type Thin-film transistor (TFT) liquid crystal Size 2.4 in. (61mm) diagonal Resolution 320 x 240 pixels Estimated battery life 8 hours Operating temperature 32° to 140°F (0° to 60°C) Storage temperature 32° to 140°F (0° to 60°C) Dimensions 3.68 x 8.25 x 2.26 in. -
Page 10: Maintenance Tips
Avoid leaving the handle in direct sunlight for long periods of time. Whenever the DCS1100 will not be used for long periods of time, remove the batteries and store the instrument in a cool, dry and well-ventilated place. -
Page 11: Warranty Information
General will repair or replace this instrument if, after examination, the company determines it to be defective in material or workmanship. This warranty does not apply to damages that General determines to be from an attempted repair by non-authorized personnel or misuse, alterations, normal wear and tear, or accidental damage. - Page 12 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Specifications subject to change without notice ©2011 GENERAL TOOLS & INSTRUMENTS NOTICE - WE ARE NOT RESPONSIBLE FOR TYPOGRAPHICAL ERRORS. MAN#DCS1100 7/13/11...
