Econo-Wrap EW-450S Light Assembly Manual

Hide thumbs Also See for EW-450S:

The following pages explain the light assembly

of an EW‐450S. Complete assembly should take

between 8‐15 minutes.

Fig. 1 shows how unit should appear upon

delivery. Fig. 2 shows the contents packaged

from warehouse.

EW‐450S – Light Assembly Guide

Fig. 2

Page 1

Fig. 1

Table of Contents

Need help?

Do you have a question about the EW-450S and is the answer not in the manual?

Page 1 EW‐450S – Light Assembly Guide Page 1 The following pages explain the light assembly of an EW‐450S. Complete assembly should take between 8‐15 minutes. Fig. 1 shows how unit should appear upon delivery. Fig. 2 shows the contents packaged from warehouse. Fig. 1 5 1 Fig. 2 ...
Page 2 EW‐450S – Light Assembly Guide Page 2 STEP 1 (Fig. 3):  Place Piece (1) onto frame of wrapper and tighten bolts.  Attach Piece (3) to Piece (1) Fig. 3 Fig. 4 STEP 2 (Fig. 4, 5, & 6):  Put Piece (5) through Piece (2) as seen in Fig. 4  Put Piece (5) through Piece (4) as seen in Fig. 4  Place Pieces (from Fig. 4) into frame of wrapper as seen in Fig. 5.  Adjust Bracket for Film Dispenser as seen in Fig. 6. Fig. 5 Fig. 6 ...
Page 3 EW‐450S – Light Assembly Guide Page 3 STEP 3 (Fig. 4, 5, & 6):  Put Piece (7) into frame of wrapper as seen in Fig. 7  Attach Piece (6) to cable as seen in Fig. 8 Fig. 7 Fig. 8 Fig. 9 Final Assembly should look like unit in Fig. 9. Please refer to the “First Time Users Guide” to start using the machine. Always read the Operator’s Manual before attempting to use a new product. ...
