You may not be able to display the computer's LCD and the external display together,
depending on the specific computer display or projector used.
Connect the AC adapter after you finish connecting all other peripheral devices. Turn
on all the peripheral devices before you turn on the computer.
See the manual supplied with your projector for more information on its installation
and use.

To connect a TV

Use the supplied AV cable to connect your TV monitor to your computer.
1 Connect the port replicator to the computer.
2 Plug the supplied AV cable into the AV/TV Out jack on the port replicator.
3 Plug the other ends of the AV cable into the TV.
Connecting a TV
Power cord
Audio In
Video In
✍
See "Selecting the Display Mode" for more information.
TV Monitor
AV cable (supplied)
Connecting an External Display
Computer
67
