Xerall X-TANKCOPTER Instruction Manual page 5

Transmitter
Heading Hold
Mode
Photo / Video
Power
Indicator
Left Stick
Notice: Taking photo and recording video are available after connecting with
smart phone.
Controller Button Functions
Power Switch: Press down the power switch to turn on the remote controller, press it down again to
turn off the remote controller.
Left Stick: To control the drone taking off /landing/ left side flying/ right side flying; To control its right
turning while flying.
Right Stick:
To control the drone forward/backward/left side flying/right side flying; To control its left
turning while flying.
Heading Hodl Mode: Press the key to the headless mode, press it again to exist the function.
Photo / Video: Press it for taking a picture, and press it for two seconds, it starts to make videos.
High / low speed: Click on this button to start the function of high/low speed mode switching.
Take Off / Landing / Emergency Stop Button:
automatic flying; Press the key while flying, the drone will land automatically or press the key for a while,
the drone will land on the ground directly.
Trimmer Mode Button:
Flight / Ground Switching:
Phone Holder Slot
Trimmer Mode Button
(Press Down)
Press the key before taking off, the drone will make
Press the key down, pull the right control rod to the direction you wanted,
then it can go under your control, release to exist.
When pressing down the key, it's changed to the flying mode, press it
again to come to the ground mode.
Flight / Ground
Switching
(Press Down)
5
www.xerall.com www.xerall.com
High/Low Speed
One Button Take
Off / Landing/
Emergency
Stop Button
Right Stick
Power Switch
