Mag Sensor Register Set

Mag Sensors Start Address = (SensorNumber-1)*7+5200
Register Description
Product Level
Water Level
Status Register
Reserved
Mag Sensor Status Register
Bit #
0
1
2
3
4
5
6
7-15

Relay Data

Relay Status Register
PS Relay Start Address = (PSRelay-1)*2+5900
Relay Start Address = (Relay-1)*2+6000
Bit #
0
1-15
Relay Status State Table
Bit Value
0
1
14
Address Offset
0,1
Signed Integer (See Length Units)
2,3
Signed Integer (See Length Units)
4
See Mag Sensor Status Register
5-8
Water Warning Active 
Water Alarm Active
Product Alarm Active
Installation Alarm Active
Sensor Missing Alarm Active
Sensor Sync Alarm Active
Sensor Float Missing Active
Reserved
Relay Status 
Reserved
Deactivated
Active
Data Format
Status Bit
Status Bit
Relay State
