Tank Alarms Register
Bit #
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14-31

Manifold Data

Manifold Data Register Set
Manifold Register Start Address = (ManifoldNumber-1)*26+3200
Register Description
Manifold Status Register
Manifold Alarms Register*
Temperature
Gross Product Volume
Net Product Volume
Water Volume
Ullage Volume
Reserved
*Note that this register does not contain all possible alarms for a tank.
Manifold Status Register
Bit #
0
1
2-31
Manifold Alarms Register
Bit #
0
1
2
3-31
12
High High Product
High Product
High Water
Low Product
Low Low Product
Precision Leak Detected
Gross Leak Detected
SCALD Leak Detected
Product Density High Limit Exceeded
Product Density Low Limit Exceeded
Float Missing
Probe Synchronization Error
No Probe Detected
Float Height Error
Reserved
Address Offset
0, 1
2,3
4,5
6,7
8,9
10,11
12,13
14-20
Manifold in Alarm
Delivery in Progress
Reserved
Low Product
Low Low Product
SCALD Leak Detected
Reserved
Status Bit
Data Format
See Manifold Status Register
See Manifold Alarms Register
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
N/A
Status Bit
Status Bit
Resolution
See Volume Units
See Volume Units
See Volume Units
See Volume Units
See Volume Units
