Tank Data - Franklin Fueling Systems INCON TS5000evo Manual

Volume Units Table
Register Value
0
1
2
Temperature Units Table
Register Value
0
1
Density Units Table
Register Value
0
1
2
Mass Units Table
Register Value
0
1
2

Tank Data

Tank Data Register Set
Tank Register Start Address = (TankNumber-1)*36+200
Register Description
Tank Status Register
Tank Alarms Register*
Product Level
Water Level
Temperature
Gross Product Volume
Net Product Volume
Water Volume
Ullage Volume
Density
Net Density
Mass
Reserved
*Note that this register does not contain all possible alarms for a tank.
Tank Status Register
Bit #
0
1
2
3-31
Unit Type
Liters
Gallons
Imperial Gallons
Unit Type
Centigrade
Fahrenheit
Unit Type
Kilograms per cubic meter
Grams per cubic centimeter
Pounds per cubic foot
Unit Type
Kilograms
Grams
Pounds
Address Offset
0, 1
2,3
4,5
6,7
8,9
10,11
12,13
14,15
16,17
18,19
20,21
22,23
24-31
Tank in Alarm
Delivery in Progress
Static Tank Test in Progress
Reserved
Data Format
See Tank Status Register
See Tank Alarms Register
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
Signed 32-bit Integer
N/A
Status Bit
Units Precision
0.1 L
0.1 gal
0.1 imp gal
Units Precision
0.1 C
0.1 F
Units Precision
0.1 kg/m^3
1 g/cm^3
0.001 lbs/ft^3
Units Precision
0.1 kg
1 g
0.01 lbs
Resolution
See Length Units
See Length Units
See Volume Units
See Volume Units
See Volume Units
See Volume Units
See Volume Units
See Density Units
See Density Units
See Mass Units
11
