Charging Batteries with the Quad Battery
Charging Cradle
Insert the battery into the Quad Battery Charging Cradle.
1.
Gently slide the battery until it reaches the bottom of the charger.
2.
Charging starts as soon as the battery is completely inserted.
3.
After charging, remove the battery from the Quad Battery Charging Cradle.
4.
Table 4-1 – Quad Battery Charging Cradle Status Indicators
LED
Red LED On
Green LED Blinking
Green LED On
Red LED Blinking
CAUTION:
Charge Status
Charging
Over 80% Charged
Fully Charged
Error Replace
•
If the red LED on the charger blinks, reseat the battery in the charger.
•
If the red LED continues to blink despite several attempts (4 ~ 5 times) to
reseat the battery, contact Oracle.
•
Charging time may vary depending on the type of the charger or the
ambient temperature.
Chapter 4
Installation and Usage
Charge Time
2.5 hours
4-5
