Monicon GTR-660 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
GTR-660
User manual
T E L ： 0 4 - 2 2 3 8 - 0 6 9 8
F A X ： 0 4 - 2 2 3 8 - 0 8 9 1
：h t t p : / / w w w . m o n i c o n . c o m . t w
W e b S i t e
E - m a i l ：
s a l e s @ m o n i c o n . c o m . t w
[1]

Advertisement

loading
Need help?

Need help?

Do you have a question about the GTR-660 and is the answer not in the manual?

Questions and answers

Related Manuals for Monicon GTR-660

Summary of Contents for Monicon GTR-660

  • Page 1 GTR-660 User manual T E L ： 0 4 - 2 2 3 8 - 0 6 9 8 F A X ： 0 4 - 2 2 3 8 - 0 8 9 1 ：h t t p : / / w w w . m o n i c o n . c o m . t w W e b S i t e E - m a i l ：...
  • Page 2 1. Introduction Panel descriptions Circuit Breaker status LED Indication of circuit breaker status Genset Indicators：When ATS transfers load from Mains to the Genset, the LED turns ON if connector 26 detects signal from ATS switch. C. Setup Keypad 1. In password entry mode, this keypad switches to next digit. 2.
  • Page 3 1. In CODE entry mode, this keypad decreases the value. 2. Under the PARAMETER setting mode, this keypad decreases the setting Enter or exit the parameter setting mode (Code: 0000) Confirm and save the settings These keypads alternately change the display of Genset information, evenlog, and error code.
  • Page 4 If Pre-fuel is activated, the fuel outputs before crank procedure. AUTO：In the Auto mode, the GTR-660 starts the engine by ATS signal and then the LCD shows preheat, if pre-heat function is enabled. After pre-heat, the engine starts to crank. If engine fails to start, the system returns to the pre-heat state and then start to crank the engine again.
  • Page 5 Input 1 IN.1 ATS input Input 0 IN.0 Low oil pressure switch L.O.P High water temperature switch H.W.T. Genset breaker status input G. switch Pickup (RPM) Pick-up Pickup (RPM) Pick-up CT 1 input CT 2 input CT 3 input CT Common input Com.
  • Page 6 2. Dimension...
  • Page 7 3. Specification A. Display 1. Mains OFF warning 2. Fuel level 3. Frequency 4. AC voltage/current 5. KW KVA KVAR (3 phase) 6. P.F. 7. RPM 8. Engine parameter settings 9. Battery voltage 10. Exerciser 11. Water temperature 12. Oil pressure 13.
  • Page 8 D. Protections Engine Generator Battery 1.High water temperature 1.Over load 1.Low voltage 2.Low oil pressure 2.Short 2.High voltage 3.Low coolant 3.High voltage 3.Charge fail 4.Over crank 4.Low voltage 4.Under voltage 5.Over speed 5.High frequency 6.Low fuel 6.Low frequency E. Specification DC input：...
  • Page 9 4. Genset Info.: Display generator inforamtion A. Event Record: Display operation history B. Parameter Modify: 1. Crank Settings 1. Detect Frequency Setting：Disable/ Enable Default：Enable Description：Check frequency value before cranking the engine. 2. Detect oil press Setting：Disable/ Enable Default：Enable Description：Check oil pressure before cranking the engine. 3.

  • Page 10: Table Of Contents

    Default：0 Description：Duration of engine idle 2. Engine Settings 1. PreAdd Fuel Time Setting：0.0~5.0(seconds) Default：3 Description：Activates fuel pump before initiating crank procedure. 2. Pre-Heat Time Setting：0~20(Seconds) Default：0 Description：Duration of Preheat before crank. 3. Energied to Stop Setting：1~30(seconds) Default：10 Description：Output duration for stop solenoid to shut down the engine. 4.

  • Page 11: Default：0

    Man Inst. Stop Setting：Disable/ Enable Default：Enable Description：Manual shutdown the Genset without cooling down the engine 3. Hour Meters 1. Acc.: Seconds/ Setting：0~59(Seconds) Default：0 Description：Set the hour meter in seconds. 2. Acc.: Minutes Setting：0~59(Minutes) Default：0 Description：Set the hour meter in minutes 3.
  • Page 12 Default：Enable Description：Activates low oil pressure protection 5. O.P. Sw. Type Setting：NC/NO Default：Norma close Description：Setup the switch to normally close or normally open. 6. L.O.P Sw. Delay Setting：0.2~6.0(Seconds) Default：1 Description：When low oil pressure occurres, timer starts before initiating shutdown. 5. Auxiliary Input 1.

  • Page 13: Default：3

    Setting：Disable/ Enable Default：Enable Description：Activates input1 function 8. Input1 Name：1.Emergency Start 2.User Define 3.Low battery Voltage 4. System fault 5.High fuel level 6. System trip 7.Insulation Fail 8.Cooling failure 9.Malfunction warning 10.Charge fail 11.Over load 12.Low water temperature 13.Preheat Default：4. Description：Define function for input 1 9.
  • Page 14 16. Input2 Delay Setting：0.2~5.0(Seconds) Default：0.4 Description：When input2 activates, timer starts before activating protection 17. Input3 Detect Setting：Disable/ Enable Default：Enable Description：Activates input3 function 18. Input 3 Name Setting：1.Low fuel level 2.User Define 3.Low battery Voltage 4. System fault 5.High fuel level 6. System trip 7.Insulation Fail 8.Cooling Fan failure 9.Malfunction warning 10.Charge fail 11.Over load 12.Low water temperature 13.Preheat Default：6.

  • Page 15: Default：2

    Setting：1.Warning 2.Alarm 3.Trip 4.Stop Default：2. Description：Setup the action when input 4 activates 25. In4 Switch Type Setting：NC/NO Default：Normal Open Description：Setup Input 4 to normally close or normally open 26. Input4 Delay Setting：0.2~5.0(Seconds) Default：0.4 Description：When input 4 activates, timer starts before activating protection 6.

  • Page 16: Setting：disable/ Enable

    4. Output 3 function Setting：1~48 Default：42. Description：Setup the function for output 3 5. Output 4 function Setting：1~48 Default：43. Description：Setup the function for output 4 7. Frequency 1. System Frequency Setting：50/60(Hz) Default：60 Description：Setup Genset frequency in 50Hz or 60Hz 2. Hi Freq. Detect Setting：Disable/ Enable Default：Enable Description：Activates high frequency protection...
  • Page 17 Description：When AC frequency is lower than setting, controller outputs trip signal. 8. Low Freq. Delay Setting：1~9(seconds) Default：3 Description：When low frequency occurres, timer starts before activating protection 9. Mini. Freq. Det Setting：Disable/ Enable Default：Enable Description：Activates minimum low frequency protection. 10. M.F. set point Setting：30~48(Hz) Default：36 Description：When sudden drop of frequency belows setting;...

  • Page 18: Default：30

    Setting：4.8~8.4/9.6~16.8(V) Default：8.4/9.6 Description：When battery voltage is below setting, controller displays battery warning. 7. Charge failed Setting：9.6~14.4/19.2~28.8(V) Default：12.6/22.6V Description：When voltage is out of range, controller displays charge fail. 9. AC Voltage 1. Gen. Output volt ： Setting 110/120/190/208/220/380V/415/440V/480V/660V/3300V/4160V/6600V/7620V/11400V Default：380V Description：Setup Genset AC output voltage 2.
  • Page 19 Setting：1.Warning 2.Alarm 3.Trip 4.Stop Default：3 Description：Setup the action when low voltage occurs 9. Low ACV set point Setting：78~110/84~120/134~190/146~208/154~220/266~380(V) Default：108/108/172/198/198/342 Description：When AC voltage is below setting, controller outputs trip signal 10. Low ACV delay Setting：0.5~5(Seconds) Default：2.5 Description：When low voltage occurred, timer starts before activating protection 11.
  • Page 20 2. Over load Detect： Setting：Disable/ Enable Default：Enable Description：Activates overload protection 3. Over load Protection： Setting：1.Warning 2.Alarm 3.Trip 4.Stop Default：3 Description：Setup the action when overload occurs 4. O. L. Set Point： Range：1~31 0.1~20.0(A) 0.1~30.0(A) 0.1~40.0(A) 0.1~50.0(A) 0.1~60.0(A) 0.1~75.0(A) 0.1~80.0(A) 0.2~100.0(A) 0.3~150.0(A) 0.4~200.0(A) 5.0~250.0(A) 6.0~300.0(A)
  • Page 21 400~2000(A) 500~2500(A) 600~3000(A) 640~3200(A) 800~4000(A) 1000~5000(A) Description：When current is above the setting, controller outputs trip signal, setup range is related to the CT ration setup. 9. Short Delay： Setting：0.1~1.0(Second) Default：0.2 Description：When AC short occurres, timer starts before activating protection 11. RPM 1.
  • Page 22 Setting：Disable/ Enable Default：Disable Description：Disengage starter motor by RPM setting 4. RPM Esc. Set point Setting：300~900(RPM) Default：480 Description：Disconnect starter motor when RPM reaches setting 5. RPM Disp. Source Setting： Alternator / Frequency Default：Freq. Description：Converts the RPM from frequency or alternator speed. 6.
  • Page 23 Setting：Disable/ Enable Default：Enable Description：Activates low oil pressure warning 5. LOP set point Setting：15~60(PSI) Default：15 Description：When oil pressure is below setting, controller displays warning message 6. HWT Value Alarm Setting：Disable/ Enable Default：Enable Description：Activates high water temperature protection. 7. HWT set point ℃...
  • Page 24 Description：Setup fuel sensor brand 13. Check before start Setting：Disable/ Enable Default：Disable Description：Setup the system to check sensors during controller boot up. 14. Cel. Or Feh ℃ Setting：°F / ℃ Default： Description：Setup water temperature unit in Fahrenheit or Celsius. 15. P.S.I or Bar Setting：BAR /PSI Default：PSI Description：Setup oil pressure unit in Bar or PSI...
  • Page 25 7. Running Interval Setting：0~510(minute) Default：4 Description：Setup the duration of each exercise 14. Maintain 1. Maintain Funct. Setting：Disable/ Enable Default：Disable Description：Activates service reminder function 2. Maintain Protect Setting：1.Warning 2.Alarm 3.Trip 4.Stop Default：4 Description：Setup the action when service reminder reaches setting 3. Maintain Code 0 Setting：0~99 Default：12 Description：Setup first two digits of service password...
  • Page 26 14~700.0(KW) 15.0~750.0(KW) 16.0~800.0(KW) 18.0~900.0(KW) 20.0~1000.0(KW) 24.0~1200.0(KW) 30.0~1500.0(KW) 32.0~1600.0(KW) 40.0~2000.0(KW) 50.0~2500.0(KW) 60.0~3000.0(KW) 64.0~3200.0(KW) 80.0~4000.0(KW) 100.0~5000.0(KW) 120~6000(KW) Description：Setup the Earth fault amperage limit 4. Over Load Delay Setting：1~20(Seconds) Description：When Earth fault reaches setting, timer starts before activating protection 16. Others 1. Protect Pending Setting：1～30 (seconds) Default：10 Description：Time delay for displaying warning or error messages after engine starts.
  • Page 27 Setting：1.Warning 2.Alarm 3.Trip 4.Stop Default：2 Description：Setup utility fail protection. Error Record: Display Malfunction history Miscellaneous 1. Time setting： Description：Setup real time clock 2. User Code： Description：Reset user password 3. Maintain Code： Description：Reset engineer password 4. Crank information： Description： a. Total count: Display total number of crank attempts. b.
