5 Commands

5.1 Identification

Register Len Access
40051 16 RO
40067 16 RO
40003 10 RO
40001 2 RO
40035 16 RW

5.2 Logs

Register Len Access
40101 1 RO
40102 1 RO
40103 1 RO
40104 1 RO
40105 1 RO
40106 1 RO
40107 1 RO
40108 1 RO
40109 1 RO
40110 1 RO
40111 1 RO
40131 1 RO
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
DID-UM-004
Revision: 3
Type Name
Identification
ASCII Model number
ASCII Serial number
ASCII Software ID
U32 Software version
ASCII Tag number
Type Name
System error log
U16 Number of errors
U16 System error 1
U16 System error 2
U16 System error 3
U16 System error 4
U16 System error 5
U16 System error 6
U16 System error 7
U16 System error 8
U16 System error 9
U16 System error 10
Test log
U16 Number of errors
vc@valcontrols.com • www.valcontrols.com
Parameter Range/Units/Notes
Description: Model number
Description: Serial number
Value: Ex: 10203 decimal = 1.02.03
Description: Software identification
number
Value: Ex: ValveTag
Description: Software version
number, e.g. 10203 = 1.02.03
Description: User configurable tag
number
Parameter Range/Units/Notes
Default: 00000
Range: 0-10
Description: Number of entries in the
log
Default: 00000
Range: 0-65535
Description: Value of newest system
error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of error
Default: 00000
Range: 0-65535
Description: Value of oldest error, if a
new error occurs this value will be
removed.
Default: 00000
Range: 0-10
7/25
