  • Page 2 Introduction C & P...
  • Page 3 Introduction C & P...
  • Page 4 Precautions Please read this manual carefully to ensure safe and proper use of the product. ! Important Negligent use or misuse of the product may cause a fire, personal injury or serious damage. ㆍDo not use damaged power plug or unsuitable outlet to prevent electronic shock or fire.
  • Page 5 Precautions ㆍDo not use this unit in moist environments like a bathroom or shower room. ㆍDo not place heavy objects on the unit. ㆍDo not attempt to disassemble, remodel, or repair the unit. It may damage the unit and will void the warranty. ㆍAfter six months usage, the lifespan of the battery may be shortened.

  • Page 6: Table Of Contents

    Contents 1. Package ..........................7 2. Instructions before use ....................18 3. Configuration ........................19 4. Hot keys & Features ....................... 18 ........................18 (1) Sound on/off ......................... 18 (2) Battery status ......................... 18 (3) Saving image ........................19 (4) Factory reset ......................
  • Page 7 Contents 6. Warranty ........................... 29 Memo ............................. 30 C & P...

  • Page 8: Package

    1. Package Thank you very much for choosing the i-loview Super HD(430S). Please check for the following items in the i-loview Super HD(430S) package : (1) Portable magnifier i-loview Super HD(430S) (2) SD card (3) Power adapter (4) Video cable (5) Carrying pouch (6) Wrist strap (7) User manual...

  • Page 9: Instructions Before Use

    2. Instructions before use (1) The battery must be fully charged for approximately 3 hours prior to the initial use. Please connect the supplied power adapter to the DC input jack to charge the battery. (2) Remove the LCD protection film before using the unit. (3) Be careful not to allow foreign material to adhere to the camera lens.

  • Page 10: Configuration

    3. Configuration ⑨ ⑱ ∞ ⑥ ⑲ ⑯ ⑦ ③ ⑪ ⑧ ④ ⑤ C & P...
  • Page 11 3. Configuration ② ① ⑰ ⑩ ⑭ ⑫ ⑮ ⑬ ⑫ C & P...
  • Page 12 3. Configuration Power on/off switch ① ㆍPower on : To turn on the unit, slide the switch to the right. ㆍPower off : To turn off the unit, slide the switch to the right again with the power on. ㆍIf you experience an operation error or malfunction, slide the power switch to the right for 6 seconds to shut down the system.
  • Page 13 3. Configuration Zoom ⊖ button ④ Press the button to reduce the size of display image. The magnification ratio as follows : ㆍLive image : 1.8x ~ 50x ㆍDigital image including magnification in snap shot mode : ~ 275x Color mode button ⑤...
  • Page 14 3. Configuration ㆍGreen text on black background mode ㆍBlue text on yellow background mode ㆍYellow text on blue background mode Snap shot button ⑥ Briefly press the button and the image on the screen will freeze. You can then zoom in/out on the still image and adjust its color and brightness. Press the button again screen will unfreeze.
  • Page 15 3. Configuration Jog button ⑧ You can move the Jog button to the left, right, up or down to navigate through menu or change menu item level. Press the Jog button to select the desired menu item. 1) Normal mode, Still image, Playback photo You can move around a magnified image by moving the Jog button left, right, up or down.
  • Page 16 3. Configuration Video out terminal ⑨ TV / You can connect to your i-loview Super HD(430S) to a TV or computer monitor. On the TV out mode you cannot access the menu. DC jack ⑩ You can insert the power adapter here to charge the battery. Battery charging indicator ⑪...
  • Page 17 3. Configuration Camera ⑬ Be careful not to allow foreign material to adhere to camera lens. If any foreign material is on the lens, wipe it off with the provided microfiber cloth. LED lights ⑭ Speaker ⑮ LCD screen ⑯ Strap hold ⑰...
  • Page 18 3. Configuration View mode selector switch ⑱ By switching this button you can select either the close-up or mid-range distance viewing mode ㆍClose-Up Mode(Flower icon) : When you are looking at objects within 1 meter of you. ㆍMid-Range Distance View Mode(Mountain icon) : When you are looking at things more than 1 meter away from you.

  • Page 19: Hot Keys & Features

    4. Hot keys & features (1) Sound on/off You can turn the sound on/off by pressing and holding down the Zoom ⊕ button and Color mode button for 3 seconds or more. (2) Battery status The status of the remaining battery power is not normally displayed, but the indicator shows up when the battery power drops to 30% of full charge.

  • Page 20: Factory Reset

    4. Hot keys & features be saved as an image file to the SD card. Once the image is saved the camera icon will disappear. (4) Factory reset If you move the Jog button up and Color mode button simultaneously for 3 seconds or more, you can reset the unit to the factory default.

  • Page 21: Returning To Personal Settings

    4. Hot keys & features (7) Returning to personal settings If you press the Zoom ⊖ button and Jog button down simultaneously for 3 seconds or more, return to the saved personal settings. (8) Menu To display the menu, press Zoom ⊖ button and Color mode button simultaneously for 3 seconds or more.
  • Page 22 4. Hot keys & features Playback photo : This allows you to display the images stored on the SD card. You can view other images by moving the Jog button left or right. Also in the Playback photo mode, you can zoom in/out the images and adjust their colors and screent brightness level.
  • Page 23 4. Hot keys & features If you want to delete the image on the screen press the Jog button. Press the Jog button one more time to confirm it. If you do not want to delete the image on the screen you can selete [NO] by moving the Jog button lef or right and press the Jog button confirm.
  • Page 24 4. Hot keys & features LED light : This allows you to on/off the LED light. C & P...
  • Page 25 4. Hot keys & features Sound volume : This allows you to adjust the sound volume. There are five(5) different levels. C & P...
  • Page 26 4. Hot keys & features Personal settings : If you select the [save] you can save your personal settings for color mode, screen brightness, led light status, sound volume and tv out format. You can select the [return] to return to the saved personal settings. C &...
  • Page 27 4. Hot keys & features TV out format : This allows you to select the screen display can be set either in NTSC or PAL format. C & P...

  • Page 28: Technical Specifications

    5. Technical specifications 1.8x ~ 275x(including digital zoom in snap shot mode) Magnification rate 1.8x ~ 50x(in live image) Natural color mode, White text on black bg, Black text on white bg, Color mode Yellow text on black bg, Black text on yellow bg, Green text on black bg, Blue text on yellow bg, Yellow text on blue bg.
  • Page 29 5. Technical specifications This unit is an EMC-registered device that can be used anywhere including residential areas. ㆍFCC part 15 Class B ㆍCISPR 22 Class B This device bears the FCC and CE approval mark Information on Disposal in other Countries outside the European Union These symbols are only valid in the European Union.
  • Page 30 6. Warranty (1) The warranty term is for one(1) year, except for the battery which is warranted for six(6) months. (2) The warranty does not cover any product problems caused due to misuse or neglect. C & P...
  • Page 31 Memo C & P...
  • Page 32 Memo C & P...
  • Page 33 Memo C & P...
  • Page 34 C & P Creativity and Personality for Assistive Technology www.chrisparkdesign.com Designed in Newport Beach, California Made in South Korea...
