- Page 1 INSTRUCTION MANUAL SludgeWatch 8200w² Fixed Sludge Level Detector Issue 01...
- Page 2 8200w² Monitor Instruction Manual ** This page is intentionally left blank ** Page 2 of 34 229844IM Issue 01 Issue Date 24/06/2019...
-
Page 3: Table Of Contents
8200w² Monitor Instruction Manual Table of Contents 1 Foreword..................................5 2 Introduction..................................6 2.1 Manual Conventions..............................6 2.2 WaterWatch² Trademark............................6 2.3 Scope of Manual..............................6 2.4 Options..................................6 2.4.1 Compatible Sensors............................. 6 2.5 Quick Overview............................... 7 2.5.1 Fault Indication............................. 7 2.5.2 Alarm Activation............................ - Page 4 8200w² Monitor Instruction Manual 6.2.5 Sensor Removal............................22 6.2.6 S0x Faults..............................22 6.3 Alarm Config (Relay outputs)..........................22 6.3.1 Alarm status..............................22 6.3.2 Alarm x Config............................23 6.4 Alarm 3 (Fault Alarm)............................24 6.5 Information................................24 6.5.1 Monitor Information............................. 24 6.5.2 Contact Information............................
-
Page 5: Foreword
8200w² Monitor Instruction Manual 1 Foreword 8200w² Monitor is another “Operator Interface” to the WaterWatch² family of measuring instruments and sensors, and has been developed to be the successor to the very popular 8100 & 8200 Monitors. Using the latest embedded processor technology, the 8200w² Monitor has been designed to encompass an easy to use and intuitive interface while providing advanced features and communication protocols to satisfy the most demanding of applications and environments. -
Page 6: Introduction
SoliTechw² IR Sensor (Range: 0-10,000 mg/l, Cable Length: 10 metres) 223899 SoliTechw² IR Sensor (Range: 0-30,000 mg/l, Cable Length: 10 metres) All the above sensors are available with 20 metre options. Contact Partech for details. Page 6 of 34 229844IM Issue 01 Issue Date 24/06/2019... -
Page 7: Quick Overview
8200w² Monitor Instruction Manual 2.5 Quick Overview 2.5.1 Fault Indication Fault indication is via the main display clearly visible on the front panel of the monitor. When there is a fault present ‘FAULT’ is displayed and fault relay will enter into the alarm condition. 2.5.2 Alarm Activation With the sensor(s) clear and not in a fault condition ‘OK’... -
Page 8: Safety Precautions
Please check the correct voltage is applied to the monitor before making live. Incorrect supply voltage can cause damage to the 8200w² Monitor. Only connect sensors from the w² range to this monitor, other Partech products without the w² reference are not compatible and may cause damage if connected. IF IN DOUBT, PLEASE ASK. -
Page 9: Service And Maintenance
Maintenance for the 8200w² Monitor should be carried out as specified in this instruction manual. Failure to carry out regular maintenance could invalidate the Warranty. Services and repairs must be carried out by a Partech engineer. Partech can provide a service contract for your system. Please ask for details. -
Page 10: Installation
Whilst all attempts have been made to ensure that these instructions are correct, common sense and good engineering practice should always be used, as every installation can present a new set of challenges and difficulties. If you are in any doubt please contact Partech or your local distributor for further information. Mechanical Installation Monitor external dimensions. -
Page 11: Fixings
8200w² Monitor Instruction Manual 4.3 Fixings The 8200w² Monitor has 3 fixing points for mounting. Follow these instructions for easy installation and mounting. Offer the monitor up to the final mounting position. Mark the wall behind with a dot halfway along the •... -
Page 12: Electrical Installation
8200w² Monitor Instruction Manual Electrical Installation Unscrew the two cover screws on the lower panel of the 8200w² Monitor to reveal the Terminals. Each terminal strip is labelled as illustrated below. (This equipment must be isolated or disconnected from HAZARDOUS LIVE voltages before access). The maximum size wire that can be terminated is 2.5mm²... -
Page 13: Dc Power Connections
8200w² Monitor Instruction Manual (Refer to BS7671, section 522 “Selection and erection of wiring systems in relation to external influences” for guidance). Shrouded Bootlace Ferrules should always be used when terminating conductors. 4.4.2 DC Power Connections The DC power connection is a 3 way terminal strip, located furthest right of the termination bank. -
Page 14: Sensor Connections
Sensors are usually supplied with 10m cables (longer cables can be provided on request). These cables can be extended to a maximum length of 100m. To ensure optimum performance, we advise the use of Partech ModTechw² cable for extensions. Partech can supply Junction Boxes to allow for easy termination of cable extensions. -
Page 15: Relay Outputs (Alarms)
8200w² Monitor Instruction Manual 4.4.6 Relay Outputs (Alarms) The relay outputs are 3 way terminal strips, located in the middle of the termination bank. The 8200w² Monitor offers 3 SPCO relay contacts that are user configurable. Please refer to the “Alarm Configuration” section of this manual for details of how to configure the relays for alarms or process control outputs. -
Page 16: Basic Operation
8200w² Monitor Instruction Manual Basic Operation Keys and Screen Navigation All menus and parameter settings are accessed using the 8200w² Monitor membrane keypad. 5.1.1 Menu Button From the measurement display screen press to show the Main Menu. While in sub menus, acts as a return to the previous menu. -
Page 17: Default Configuration
8200w² Monitor Instruction Manual Press to highlight the menu required, and press to select. Press at any time to return back to the previous menu. Note: If no key is pressed for 2 minutes, the monitor will default back to the measurement display screen. -
Page 18: Operational Menus
8200w² Monitor Instruction Manual 6 Operational Menus Monitor Config Menu The MONITOR CONFIG menu is used to set up the core monitor functions, including backlight, bleeper function, time and date. This menu option also provides access to some advanced configuration and reset functions. -
Page 19: Language
Enable Service Mode Service mode allows the user access to diagnostic information and detailed set- up parameters. This will normally be used under the guidance of a Partech engineer, see section 7. 229844IM Issue 01 Issue Date 24/06/2019 Page 19 of 34... -
Page 20: Sensor Config
8200w² Monitor Instruction Manual Sensor Config The monitor leaves the factory with no sensors pre-installed. Before attempting to configure a measurement, the sensor must be installed. At this stage it is worth reviewing the contents of the sensor manual(s) to ensure each sensor has been mechanically and electrically installed correctly. NOTE: Once the Sensors have been wired, unplug each 4-way connector from the 8200w²... -
Page 21: S:0X Info
.A tick will appear next to the identified fault if there is a sensor fault alarm. This function provides a range of diagnostic information that may be requested by Partech for fault finding As can be observed from screenshots on the right, Page 1 displays sensor type and sensor serial number. -
Page 22: Sensor Removal
8200w² Monitor Instruction Manual 6.2.5 Sensor Removal If a sensor is no longer required, the sensor configuration can be removed from the 8200w² monitor in the following way: From the SENSOR CONFIG screen, use to highlight the sensor to be removed; i.e. ‘S:01 SoliTechw² IR (0-200)’, then press to select. -
Page 23: Alarm X Config
8200w² Monitor Instruction Manual 6.3.2 Alarm x Config From the MAIN MENU, select ALARM CONFIG and press Highlight ALARM (X) CONFIG using and press A list will be displayed showing the available options to configure the alarm selected. Highlight the required option and press Listed below are the descriptions of each option. -
Page 24: Alarm 3 (Fault Alarm)
Hysteresis settings are missing from the menu choice. Information This section provides basic information about the equipment that you have purchased and contact details for Partech. From the MAIN MENU, ensure INFORMATION is highlighted (if not, press to highlight the option) then press 6.5.1... -
Page 25: Lock Config
Care should be taken when changing the password. If the password is lost, it may be necessary for Partech to visit the instrument to unlock the monitor and reset the password. From the LOCK CONFIG menu press to select CHANGE PASSWORD and press This screen requests the OLD password. -
Page 26: Sludge Blanket Level Detection
8200w² Monitor Instruction Manual 7 Sludge Blanket Level Detection Description The typical sludge blanket level detection installation is in a settlement tank. The system is made up of a single or dual sensor configuration and a monitor. There will also be associated mounting hardware, which is dependent upon the applications requirements. -
Page 27: Blanket Not Detected
8200w² Monitor Instruction Manual the Alarm x Set Delay and Alarm x Reset Delay are set to zero so the current alarm status is accurately reported in real time. 7.3.1 Blanket not detected If the sensor is not detecting the sludge blanket and the OK status remains asserted when the sensor is in the blanket, take the following action: With the sensor in the sludge blanket, take note of the % solids value on the display. -
Page 28: Menu Tree
8200w² Monitor Instruction Manual 8 Menu Tree Below is the menu structure of the 8200w² Monitor: Main Menu Monitor Config Bleeper Backlight Contrast Language Set Date/Time Enable Service Mode Sensor Config Sensor Status S:0x Sensor Type Option S:0x Info S:0x Averaging S:0x Remove S:0x Faults Alarm Config... -
Page 29: Maintenance
8200w² Monitor Instruction Manual Maintenance 9.1 On-Board Battery Backup Replacement The monitor is fitted with a battery backup for the real time clock function. Failure of the battery will only effect the time (all parameters, settings and process data are stored electronically and is not effected by a failed battery). -
Page 30: Technical Support
Digital photos can also be useful to determine correct installation and suitability to the application. • 10.1 Returning Equipment for Repair If equipment needs to be returned to Partech for repair or service the following address should be used: SERVICE DEPARTMENT PARTECH INSTRUMENTS ROCKHILL BUSINESS PARK... -
Page 31: Technical Specification
8200w² Monitor Instruction Manual 11 Technical Specification 11.1 Physical Dimensions ........213 x 185 x 95mm (HxWxD) Enclosure Material......Polycarbonate (PC) Weight..........1.4Kg Temperature........-20 to +60 C, 0-95% Relative Humidity, Non-Condensing Mounting.........Wall or Rail Mounting Bracket or Enclosure Option Available Cable Entries........1x M20, 4x M16, 1x M12 11.2 User Interface Display ...........Graphic LCD, Black on White, Transreflective Viewing Area........78 x 59mm... - Page 32 8200w² Monitor Instruction Manual 229844IM Issue 01 Issue Date 24/06/2019 Page 32 of 34...
- Page 33 8200w² Monitor Instruction Manual 229844IM Issue 01 Issue Date 24/06/2019 Page 33 of 34...
- Page 34 Partech Instruments Rockhill Business Park, Higher Bugle, St Austell, Cornwall,PL26 8RA,UK Tel: +44(0)1726 879800 Email: info@partech.co.uk Web: www.partech.co.uk...
