Summary of Contents for Biosan ES-20/80
-
Page 3: Table Of Contents
Care and maintenance ................... 13 Warranty ......................... 14 EU Declaration of conformity .................. 15 About this edition of user instructions The current edition of the user instructions applies to the following models and ver- sions of Orbital shaker-incubator: ES-20/80 ......................V.1AD... -
Page 4: Safety Precautions
Safety precautions The following symbols mean: Caution! Make sure you have fully read and understood the present Manual before using the equipment. Please pay special attention to sections marked by this symbol. Caution! Hot surface! Incubator surface and inner camera may become very hot during use. -
Page 5: General Information
General information ES-20/80 shaker-incubator for biotechnological and pharmaceutical laboratories is a professional category equipment. The typical applications include - microbial and cell culture cultivation, protein expression, solubility studies, general mixing, as well as other various applications in the fields of biology and chemistry. The unit is equipped with a newly devel- oped triple eccentric mechanism for platform motion that provides supreme balancing char- acteristics, superior reliability and quiet operation. - Page 6 4.2.2. Optional accessories: HSP-30/100 platform ................. on request HSP-16/250 platform ................. on request HSP-9/500 platform ................... on request HSP-6/1000 platform ................. on request PP-400 platform ..................on request UP-168 universal platform ................. on request HSC-50, HSC-100, HSC-250, HSC-500, HSC-1000 clamps for UP-168 .. on request TR-21/50 test tube rack for UP-168 ............
-
Page 7: Stacking
Washer Lock washer Hex driver 5.2. Aquiring a kit. To purchase the kit, contact Biosan or your local Biosan representa- tive, with information from the section Ordering information. 5.3. Getting started. 5.3.1. Unpack the kit. Unpower the units and disconnect the power cables. - Page 8 5.5.3. Top unit (figure 6): 5.5.3.1 Set the top unit atop of the middle unit. 5.5.3.2 Connect the units with four plates. A plate requires four screws, each with a washer and a lock washer on it (fig. 3). Fix the screws tightly. 5.6.
-
Page 9: Operation
Operation 6.1. Connect the unit to a grounded power socket. Set the Power switch on the rear panel to position I (on). 6.2. The display turns on. From top to bottom, display shows: Current date and time; Actual and set temperatures; Actual RPM, set RPM and timer;... - Page 10 6.6. If the time is not set (set time is 00:00), the Run Stop key will start continuous oper- ation of the unit until the Run Stop key is pressed again. 6.7. The platform motion can be stopped at any time by pressing the Run Stop key. In this case, the program realisation and the platform motion will stop and the timer will switch into the STOP mode saving previously set time.
-
Page 11: Specifications
80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C. Biosan is committed to a continuous programme of improvement and reserves the right to alter design and specifications of the equipment without additional notice. -
Page 12: Ordering Information
Version Description Catalogue number ES-20/80 V.1AD 230 V, 50/60 Hz, no platforms BS-010167-A05 8.2. To inquire about or order the optional accessories, contact Biosan or your local Bio- san representative. 8.3. Optional accessories for ES-20/80: Catalogue num- Model Description HSP-30/100... -
Page 13: Care And Maintenance
9.3.2. For decontamination, it is recommended to use a special DNA/RNA removing solu- tion (e.g. Biosan PDS-250, DNA-Exitus Plus™, RNase-Exitus Plus™). 9.4. Fuse replacement. Disconnect the power cable from the mains. Disconnect the power cable from the socket on the rear of the unit. -
Page 14: Warranty
To obtain the claim form, visit Technical support page on our website at link below. 10.5. Extended warranty. For ES-20/80, the Smart class model, extended warranty is a paid service. Contact your local Biosan representative or our service department through the Technical support section on our website at the link below. -
Page 15: Eu Declaration Of Conformity
11. EU Declaration of conformity Unit type Shakers-incubators Models ES-20, ES-20/60, ES-20/80 Serial number 14 digits styled XXXXXXYYMMZZZZ, where XXXXXX is model code, YY and MM – year and month of production, ZZZZ – unit number. Manufacturer SIA BIOSAN Latvia, LV-1067, Riga, Ratsupites str. 7/2...
