4. Replacing the goggle skirt
0 Remove the skirt with frame damaged by pulling off.
@Replace a new skirt frame into a goggle frame at 4 locking positions until
hears click sound.
5. light holder and Clip shield assembly
Must attach holder from back to front/ detach from front to back , otherwise
can cause breakage.
Be sure all tabs(3pomt) on a flash hol der are securely locked over shield frame.
-.••
0
-.••
Be sure goggles are securely locked in shield

General care and maintenance

• Do not expose goggles to excessive force or impact.
�
Lll •
Do not use solvents or strong chemicals
• Do not allow goggles to get wet or expose to extreme temperatures.
• Clean with cloth dampened with glass cleaner or mild detergent.
�----
1. Trouble Shooting
Trouble
Not switching- Auto Stop welding or cutting 1mmed1ately. Make sure the
lens stays light and lens 1s turned On.
does not darken when If power 1s On, check the shade settings. Also review
welding or cutting. sens1t1vity recommendations and adjust sens1t1v1ty 1f
possible. Clean the lens cover and sensors of any
obstructions. Make sure the sensors are facing the arc.
Not switching- Auto Reouce Sens1t1v1ty setting. In extreme light cond1-
lens stays dark after t1ons. 1t may be necessary to reduce the surround­
the arc 1s extinguished. ing light levels.
If the lens remains dark. press the Auto On/Off
or the auto lens stays
dark when no arc 1s button to return lens to the clear state.
present Move goggles away from light source.
Switching or Flicker Review the sensit1v1ty setting recommendation and
ing- the auto lens increase the sens1t1v1ty if possible. Be sure the arc
darkens then lightens sensors are not being blocked from direct access to
while the welding or the arc light.
cutting arc is present. Check the lens cover for dirt and spatter that may be
blocking the arc sensors. Move doser to arc.

2. Warranty

Servore auto-darkening goggles are warranted for 2 years from the date of
purchase. Proof of purchase 1s required for warranty transaction so 1t 1s
imperative that a copy of the original invoice or sales receipt be retained.
For warranty transaction, contact our Servore Distributor
- j
- -
Remedy
