Progres Agronic 2000 Series Instruction Manual

Progres Agronic 2000 Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INDEX
Sec.
Theme
INDEX / PRESENTATION
1.
BASIC FUNCTIONAL DESCRIPTION
2.
INTRODUCTION TO THE MANUAL
Sections for the installer
3.
DIMENSIONS
4.
INSTALLATION
4.1
Placing the unit
4.2
Connection
4.3
Guide to malfunctions
4.4
Additional information for the instal-
lation of options
5.
TECHNICAL CHARACTERISTICS
6.
PARAMETERS
6.1
Fertilizer parameters
6.2
Filter cleaning parameters
6.3
Various parameters
6.4
Clock parameters
6.5
Additional information for diesel op-
tion parameters
PRESENTATION
We wish to take this opportunity to thank you for the confidence in us which you have demonstrated in ex-
pressing interest or acquiring the AGRÓNIC 2000.
This confidence, for our part, stimulates our efforts to meet and surpass the expectations of our clients to jus-
tify the traditional quality of our products.
This manual will explain the specification of the equipment as well as its installation and use.
However, if after reading this you still have any doubts, contact us and we will happily answer them.
INSTRUCTION
MANUAL
VERSION 4
Page
1
2
3
3
4
4
5
7
8
10
11
11
12
12
14
15
Sections for the user
7.
USE
7.1
Programs
7.2
Manual
7.3
Totals
7.4
Consultation
8.
ADDITIONAL INFORMATION FOR
VOLUME
8.1
Parameters
8.2
Programs
8.3
Totals
8.4
Consultation
8.5
Anomalies
9.
ADDITIONAL INFORMATION FOR
DIESEL OPTION
9.1
Consultation
9.2
Anomalies
9.3
Malfunctions
NOTES
1
16
16
19
19
20
22
22
22
22
22
22
23
23
23
23
24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Agronic 2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Progres Agronic 2000 Series

Summary of Contents for Progres Agronic 2000 Series

  • Page 1 INSTRUCTION MANUAL VERSION 4 INDEX Sections for the user Sec. Theme Page INDEX / PRESENTATION Programs BASIC FUNCTIONAL DESCRIPTION Manual INTRODUCTION TO THE MANUAL Totals Sections for the installer Consultation ADDITIONAL INFORMATION FOR DIMENSIONS VOLUME INSTALLATION Parameters Placing the unit Programs Connection Totals...

  • Page 2: Basic Functional Description

    1. BASIC FUNCTIONAL DESCRIPTION CLEANING OF FILTERS This can be configured from 0 to 9 filters, with This equipment is for the control of the irrigation variable washing time. Pause time between filters. system, fertilization, fertilizer mixing, pumps and the The washing sequence can be started by the cleaning of the filters, with the detection of malfunc- pressure difference and/or the time or volume of water...

  • Page 3: Introduction To The Manual

    - Option with outlets for latch valves (pulses) and minimum electric consumption. Due to its low elec- Examples: tric consumption of the equipment and its electro- - If we have 2 irrigation sectors, 1 fertilizer and 2 valves, this version is very suitable for installations filters, the model 2006 is sufficient (2+1+2 which work with a battery and which have not got =5).

  • Page 4: Installation

    3. DIMENSIONS 4. INSTALLATION 4.1. PLACING THE UNIT There are also two more holes in the inside of the Place the unit at the right position and height. connection housing. Avoid direct sun exposure, humidity, dust and vibra- In the “built-in” model, a hole is to be done in the tions.
  • Page 5 4.2. CONNECTION would increase the equipment power tension mo- mentarily. The unit has to be installed following the prevail- To replace the fuse, half turn the fuse cover and ing regulations for electrical installations. insert another of the same value. In the “box”...
  • Page 6 same units where it stopped. There is a program- The “outlet fuse” protects from overloads and mable delay for this detection. short-circuits. To change it, just half turn the cover of • PS Program start. A program will be activated by the fuse holder, take it out and replace it with a similar one.
  • Page 7 Outlet assignation tables according to unit models. Model Outlets Input 230 V or 115 V, Out- Input 12 V, Outlets 12 V Input 12 V, Outlets 12 V lets 24 V Latch Option 3 cables Box terminal, connected to earth (Built-in model) Stop common Outlet common 24 V.
  • Page 8 4.4. ADDITIONAL INFORMATION FOR THE amps. Its outlet has to be connected to the terminal cable “50” of the key. INSTALLATION OF OPTIONS If the engine stops by electromagnet, a supple- mentary relay will be installed between the former one 4.4.1.
  • Page 9 4.4.2. Latch option The other cable, normally white, will be con- The low consume of the equipment (0.12 nected to the controller, to the outlet corresponding to watts/hour), and its latch electrovalves, make this op- its sector or to the “M” general valve outlet. tion suitable for those installations which work with battery.

  • Page 10: Technical Characteristics

    5. TECHNICAL CHARACTERISTICS Power supply Units for alternating current Units for direct current 230 Vac or 115 Vac 12 Vdc +10% -5% Voltage +5%-10% CAT II Frequency 50-60 Hz ---------- Energy consume Below to 58 VA (at rest 2.7 VA) Below to 7 W (at rest 0.6 W) Fuses Input...
  • Page 11 6. PARAMETERS • Fertilizer pulse value (0 to 1000 cl). • Assignation of functions to the inputs. • Delay for temporary malfunction TM (0 to 999”). To do any work with the controller, except “view”, • Delay for general malfunction GM (0 to 999”). press the FUN key (Functions) and the following •...

  • Page 12: Various Parameters

    If there are several fertilizers, the unit allows a Pause pump outlet of fertilizer, which is connected whenever between filters= 07” one of them is connected (for various tanks connected to the same injector). The following question refers to the irrigation time between two cleaning cycles, going from 0 to 9999 Fert.
  • Page 13 For the fertilizer counter, the pulse value is in While a filter cleaning is being carried out, the centiliters. For example, if the counter emits a pulse temporary malfunction or general malfunction inputs every liter, the value will be 100 CL. are not taken into account.

  • Page 14: Clock Parameters

    Between 1 and 4 sectors may be associated to Next, the following screen is displayed, asking if the four groups. the clock should be interrupted in case of a failure in the power supply. Group 1 : 02 03 06 00 Clock stop on power failure, Yes/No = No In the program referring to the groups of sectors,...
  • Page 15 6.5. ADDITIONAL INFORMATION DIESEL OPTION PARAMETERS 18 17 The oil pressure gauge “OP” will be connected to input n.5. It has a double function, first it detects the In the diesel version it asks for the start and stop engine starting and, once the engine has started, it times.
  • Page 16 7. USE Introducing the desired number, all the informa- tion of this program will be displayed. With the key This is the chapter the user should mainly know marked with an upwards arrow, the different programs as it contains the instructions which will be used more will be displayed.
  • Page 17 After entering the last data of a program, the cur- sor will be placed again in the program number. In series fertilization, the sum of the times of dif- ferent fertilizers and plus the configured post-irrigation time, plus the separation time between fertilizers (if more than one is used), must be inferior or equal to the irrigation time.
  • Page 18 gram of the sequence. To reactivate it, the day or days 7.1.3. Program by frequency activation of the week should be re-entered. In order to make different irrigations activations in one sector or in a group of sectors, only the program 1 Example of stop of the previous sequence have the variable of activation number and frequency between them.
  • Page 19 Erase previous Outlet number = 00 program (Yes/No) ? 08 03 00 00 00 00 Mon.18:14 - MANUAL - 7.2. MANUAL If we choose Function 2 (MANUAL) of the functions menu, this screen will appear asking what we want to do with the manual control.
  • Page 20 7.4. CONSULTATION We have to take into account that every input has a The work of the controller can be reached with the function assigned in the “parameters” section. VIEW key. If the filter cleaning is being carried out, the fertilizer Pressing the VIEW key several times, different mes- (if there is one) is stopped temporarily and the unit will sages and data will appear on the screen.
  • Page 21 can work at the same time is set in the installer con- The following screen warns that there has been a figuration). stop of the unit by MANUAL CONTROL, waiting to be reactivated. *Program not enter* The outlets are deactivated but the program runs its course.

  • Page 22: Additional Information For Volume

    8. ADDITIONAL INFORMATION FOR 8.4. CONSULTATION VOLUME For every sector being irrigated, it will display the quantity of cubic meters left to irrigate and the liters of When configuring the unit to irrigate and fertilize in fertilizer which are still to be applied. volume units, m and liters respectively, the following changes in the “functions”...

  • Page 23: Additional Information For Diesel Option

    9. ADDITIONAL INFORMATION FOR When detecting a failure of the oil pressure, an DIESEL OPTION anomaly will be recorded, showing the day and time when it took place. The detection is delayed 10 sec- onds. This option increases the functions of the AGRÓNIC 2000 with the control of an internal combus- tion engine (diesel or petrol) with an electronic starter.
  • Page 24 NOTES: R-1189-3...
