  • Page 1 TXIO Third-Party Equipment Interface Toshiba TCC-Link Installation and User Guide www.microtrol.co.uk...
  • Page 3: Table Of Contents

    Contents 1. Important Information......................2 2. Product Overview ........................3 3. Connection Details......................... 3 3.1 Power Supply ..........................4 3.2 HVAC Communications Network ( TCC-LINK )................4 3.3 Relay Output...........................4 3.4 Error Input ............................4 3.5 Thermistor Input ..........................4 4. Configuration ......................... 5 4.1 S1 Bitswitch Function ........................5 4.2 S2 Link Function..........................6 4.3 LED Functions ..........................7...
  • Page 4: Important Information

    1. Important Information All electrical work should be carried out by a competent person and wiring must be in accordance with the national electrical installation regulations. Ensure that installation work is done correctly using the information contained in this manual. Make all connections securely so that any outside forces acting on the cables are not applied to the terminals.
  • Page 5: Product Overview

    2. Product Overview The Black Pear TXIO enables third party equipment to be controlled and monitored with the Smart Touch central controller and Toshiba versions of the Black Pear BMS interface. Each TXIO can be given a TCC-Link central address and will then appear on the Smart Touch or Black Pear interface as a simple unit with On/Off, Error and Return Air parameters.
  • Page 6: Power Supply

    3.1 Power Supply The TXIO requires a 100-240v AC supply and has a consumption not exceeding 2VA. The internal fuse is rated T630mA. THIS EQUIPMENT MUST BE EARTHED 3.2 HVAC Communications Network ( TCC-LINK ) Can be connected to either U1/U2 or U3/U4 networks. These are non-polarized.
  • Page 7: Configuration

    4. Configuration Link Bitswitch Fig. 2 LEDs and Config Switches 4.1 S1 Bitswitch Function S1-1 On = 100 ohm terminator connected across the TCC-Link lines Off = No terminating resistor. Note:- Only one terminating resistor should be enabled per network S1-2 On = Auto Restart (retain the I/O state as it was at power down) Off = Start in the OFF condition...
  • Page 8: S2 Link Function

    S1-3 to S1-8 Set the address of the unit; S1-3 = MSB : S1-8 = LSB The address is the binary value of S1-3 to S1-8 plus 1. (all switches off = 1, all switches on = 64) 3 4 5 6 7 8 3 4 5 6 7 8 3 4 5 6 7 8 3 4 5 6 7 8...
  • Page 9: Led Functions

    4.3 LED Functions LED 3 (Blue) Power (Flashing = ‘In Error’) LED 2 (Red) TCC-Link Comms Flashes for each message LED 1 (Amber) Output State (On = Active)
  • Page 10: Appendix A : Physical Dimensions

    Appendix A : Physical Dimensions 110mm 107mm 33mm Power Supply Fig. 3 Dimensions...
  • Page 11: Appendix B : Document Revision History

    Appendix B : Document Revision History Date Document Ver Firmware Ver Comments 01/07/2017 v1.00 v1.10 First version converted from preliminary instructions. 05/07/2017 v1.01 v1.10 Converted to booklet...
