- Page 1 RAS-M Interface Toshiba TCC-Link Installation and User Guide www.microtrol.co.uk...
- Page 3 Contents 1. Important Information......................2 2. Product Overview ........................2 3. Supplied Parts........................2 4. Connection Details......................... 3 5. Installation ..........................3 6. Configuration ......................... 4 6.1 S1 Bitswitch Function ........................4 Appendix A : Document Revision History ................5...
-
Page 4: Important Information
To dispose of this product, consult your dealer. 2. Product Overview The Black Pear RAS-M interface provides a TCC-Link connection for new style Toshiba MIRAI air-conditioner units eg. RAS-07BKVG-E. It replaces the existing air-conditioner infra-red PCB but still allows manual control using the I/R remote controller. -
Page 5: Connection Details
4. Connection Details All electrical work should be carried out by a competent person and wiring must be in accordance with the national electrical installation regulations. Connect to 2-wire TCC-Link adapter cable (supplied) Connect to existing RAS 8-way wiring harness 5.Installation The RAS-M interface replaces the existing IR receiver pcb in the RAS unit. - Page 6 6. Configuration 6.1 S1 Bitswitch Function S1-1 On = 100 ohm terminator connected across the TCC-Link lines Off = No terminating resistor. Note:- Only one terminating resistor should be enabled per network S1-2 On = Auto Restart Off = Start in the OFF condition Note:- S1-2 overrides the normal auto restart feature S1-3 to S1-8 Set the address of the unit;...
- Page 7 Appendix A : Document Revision History Date Document Ver Firmware Ver Comments 19/01/2018 v1.00 v1.13 First version converted from preliminary instructions to booklet.
- Page 8 Microtrol Ltd 16 Elgar Business Centre Moseley Road Hallow Worcester WR2 6NJ Tel: +44 (0)1905 641910 Email: sales@microtrol.co.uk...
