Splicer and Switcher. When it is in Splicer mode, a maximum of 4 DVI output connectors can be used together for output, which can realize an up to 8KK loading capacity of each J6 unit. When it is in Switcher mode, a maximum of 2 DVI output connectors can be used together for output, which can realize an up to 4KK loading capacity of each J6 unit.
Page 5
You can create at most 10 custom presets and load the preset simply by clicking one button. Layer layout management The J6 is built-in with 7 layer layouts. You can load one of the layer layouts to quickly lay out the layers. Multiple operation modes You can operate the J6 via its front panel, the V-Can smart control software or C1 event controller.
J6 Seamless Switcher User Manual Appearance Front Panel Button Description ON/OFF Press ON to power on the device. button Press OFF to power off the device. Layer Press a layer button to open the corresponding layer and enter the layer settings menu, or press buttons the layer button to input the corresponding number on the button.
Each group includes a main connector and a backup connector. The J6 supports dual-link DVI output mode. When the output is set to dual-link mode, DVI1 and DVI3 are used as output connectors, while DVI2 and DVI4 are unavailable.
J6 Seamless Switcher User Manual Monitor An HDMI connector is used as monitoring connector to monitor all input sources, single input source, PVW and PGM. Control Connector Description ETHERNET Communicate with PC or connect to the network. USB (Type-B) Connect to the PC for device control.
J6 Seamless Switcher User Manual Applications The J6 supports two system modes: Splicer and Switcher. The connections for two modes are shown in Figure 3-1 Figure 3-2. Figure 3-1 Connections for Splicer mode Figure 3-2 Connections for Switcher mode www.novastar.tech...
J6 Seamless Switcher User Manual Menu Operations Operation Instructions Knob On the home screen, pressing the knob enters the operation menu screen. On the operation menu screen, rotating the knob selects a menu item, and pressing the knob confirms the selection or enters the submenu.
Page 11
: The Genlock function is abnormal or the Genlock source is lost. : The Genlock function is turned off. System mode The J6 supports two system modes: Splicer and Switcher. : Switcher mode : Splicer mode...
4.3.1 Output Mode The four group of DVI connectors of the J6 can be configured as single link DVI output or dual link DVI output. When the output mode is different, the connection of the device output connector is different.
J6 Seamless Switcher User Manual 4.3.2 Screen Layout Screen layout is the screen mosaic mode. The screen layout will vary according to Output Mode and System Mode. System mode: Splicer − When the Output Mode is SL, the following 8 screen layouts are supported.
Output connector settings Layer Settings The J6 supports one BKG and six layers. You can set the layer layout simply by selecting a layout from Layer Layout or set the parameters for each layer. On the main menu screen, rotate the knob to choose Layer Settings > Layer Layout to enter the layer layout settings screen.
Page 15
Figure 4-11 BKG image Pure Color BKG The J6 supports pure color BKG. When the BKG type is Pure Color, you need to set the individual R, G and B value for the pure color BKG. Figure 4-12 Pure color BKG...
Preset Settings The J6 supports up to 10 user presets. After the layer settings are complete, you can save the settings as a preset and load the preset. When the preset name is in green, the current preset has data and can be loaded or cleared.
J6 Seamless Switcher User Manual Figure 4-15 Preset settings Input Settings On the input settings screen, you can set the input resolution. The standard resolution and custom resolution are both supported. Figure 4-16 Standard resolution Figure 4-17 Custom resolution Display Control On the display control screen, you can set the transition effect and transition duration, freeze the screen or make the screen fade to black, as well as adjust the input, output and layer color.
Figure 4-19 Test pattern Pure Color Test whether the screen can display the color normally. The J6 provides 8 pure colors. Gradient Test whether the screen can display the image normally. The J6 provides 8 gradients. ...
Figure 4-21 Advanced settings 4.10.1 System Mode The J6 supports two system modes: Splicer and Switcher. When different system mode is selected, the device loading capacity and operations are also different. Splicer: All the operations to the layers will be displayed on the LED screen simultaneously.
J6 Seamless Switcher User Manual 4.10.3 Fn Settings When different system mode is selected, the Fn button function may vary. In Splicer mode, after you have completed the Fn settings, press the Fn button to enter the settings screen of the function that you have set for the button.
When the device is connected to the control PC via both USB and LAN cables, you can select LAN Preferred (default) or USB Preferred. When LAN Preferred is selected, the J6 is controlled by the control PC via the LAN cable. When USB Preferred is selected, the J6 is controlled by the control PC via the USB cable.
IP addresses of other devices to avoid network conflict. You can select Reset to reset the IP Address and Subnet Mask to the defaults. Language J6 currently supports “Chinese” and “English”. Users can switch languages as required. Figure 4-31 Language...
When multiple J6 units are connected to V-Can, the control PC where V-Can is installed must be on the same LAN with the J6 units. V-Can will automatically search all the J6 units on this LAN and connect all of them.
The C1 event controller is a hardware console of NovaStar specifically designed for video processing products. The C1 offers two LCD screens. The left one performs the input and output monitoring for the J6. The right one, together with the front panel buttons, allow you to perform operations and control of the J6.
Page 25
J6 Seamless Switcher User Manual Figure 6-2 Adding devices After the devices are added, you can view the information of those added devices on the Device List page, as shown in the figure below. Figure 6-3 Device list Step 4 next to the device IP address to enter the device properties screen.
Page 26
J6 Seamless Switcher User Manual Figure 6-4 Device properties Input: Set the input resolution and input color. Output: Set the output resolution and output color. Easy Mosaic: By entering the screen width and height, the system will come up with a mosaic plan automatically.
J6 Seamless Switcher User Manual Troubleshooting Problem Solution LED screen is not lit Make sure the power is properly connected and switched on, and the LED screen is connected properly and works normally. DVI has no output image Make sure the input channel has input image and the image is displayed correctly.
J6 Seamless Switcher User Manual Specifications Input resolution up to 1920× 1200@60Hz and downward compatible Connector Input HDCP 1.4 3G-SDI Input resolution up to 1920× 1080@60Hz and downward compatible 3G-SDI loop output HDMI1.3 Input resolution up to 1920× 1080@60Hz and downward compatible HDCP 1.4...
Page 29
J6 Seamless Switcher User Manual Power consumption Operating Operating environment 0℃~60℃ temperature Storage -20℃~60℃ temperature Dimensions 482.6mm× 379.5mm× 94.7mm Physical specifications Weight 3810g www.novastar.tech...
