Sony CD Walkman D-ES55 Operating Instructions

Compact Disc
Compact Player
Operating Instructions
About area code
The area code of the player you purchased is shown on upper left of the bar
code label on the package.
For accessories supplied with your player, check the area code of your model
and refer to "Supplied accessories" toward the end of this manual.
D-ES51
D-ES55
Sony Corporation 1998 Printed in Japan
Welcome!
INFORMATION
Listening for many hours at maximum
Thank you for purchasing the Sony
volume may damage your hearing.
Compact Disc Compact Player.
Before operating your player, please
For the customers in the USA
read this manual and retain it for
This equipment has been tested and found to
future reference. comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
About this manual
protection against harmful interference in a
The instructions in this manual are for the
residential installation. This equipment
D-ES51 and D-ES55. Before you start reading,
generates, uses, and can radiate radio frequency
check your model number.
energy and, if not installed and used in
accordance with the instructions, may cause
Owner's Record
harmful interference to radio communications.
The model and the serial numbers are located at However, there is no guarantee that interference
the bottom. Record these numbers in the spaces will not occur in a particular installation. If this
provided below. Refer to them whenever you equipment does cause harmful interference to
call upon your Sony dealer regarding this
radio or television reception, which can be
product. determined by turning the equipment off and on,
the user is encouraged to try to correct the
Model No. __________ Serial No.__________ interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
WARNING
- Increase the separation between the equipment
and receiver.
To prevent fire or shock - Connect the equipment into an outlet on a
circuit different from that to which the receiver
hazard, do not expose
is connected.
the unit to rain or - Consult the dealer or an experienced radio/TV
technician for help.
moisture.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
To avoid electrical
equipment.
shock, do not open the
For the customers in Australia
cabinet. Refer servicing
The supply cord of the AC power adaptor cannot
to qualified personnel
be replaced; if the cord is damaged, the AC
only. power adaptor should be discarded.
For the customers not in Poland
CAUTION
The mark on the unit is valid only for
The use of optical instruments with this product
products marketed in Poland.
will increase eye hazard.
For the customers not in Europe
The CE mark on the unit is valid
only for products marketed in the
European Union.
For the customers not in Russia
The mark on the unit and package is
valid only for products marketed in Russia.
3-862-322-22 (1)
Playing a CD right
away!
If you want to play a CD right now, choose to use your player on house
current. Other choices are the following three: rechargeable battery, dry
batteries (see "Power Sources" on the reverse side) and car battery.
1
Connect
Headphones
2
DC IN 4.5 V
For models supplied with AC plug adaptor
If the AC power adaptor does not fit the wall outlet, use the AC plug adaptor.
2
Place a CD
1
Unfasten the buckle.
2
Open the lid.
Label side up
3
4
3
Play
1
Press ^.
2
Adjust the volume.
To Press
Pause ^
Resume play after ^
pause
Find the beginning
= once**
of the current track
(AMS*)
Find the beginning = repeatedly**
of previous tracks
(AMS)
Find the beginning
+ once**
of the next track
(AMS)
Find the beginning + repeatedly**
of succeeding
tracks (AMS)
Go forward
Hold down
quickly
+**
Go backwards Hold down
to a wall
quickly =**
outlet
AC power adaptor
*AMS = Automatic Music Sensor
**These operations are possible during both
play and pause.
To remove the CD
Remove the CD while pressing the pivot.
Notes on display
• When you press ^ (when RESUME is set
to OFF), the total number of tracks in the
CD and the t2otal playing time appear for
about 2 seconds.
• During play, the track number and the
elapsed playing time of the current track
appear.
• During pause, the elapsed playing time
flashes in the display.
• Between tracks, the time to the beginning of
the next track will appear with the "–"
indication.
Notes on handling CDs
• To keep the CD clean, handle it by its edge.
Do not touch the surface.
• Do not stick paper or tape onto the CD.
• Do not expose the CD to direct sunlight or
heat sources such as hot air ducts. Do not
leave the CD in a car parked under direct
sunlight.
Fit the CD to the pivot and close the
lid.
Fasten the buckle securely by pressing
both sides of the buckle.
Not these ways
To stop play, press p.
zOther Operations
Playing tracks in random
order
(Shuffle Play)
Playing tracks repeatedly
(Repeat Play)
You can play the tracks in a CD in random
order.
You can play tracks repeatedly in normal,
INTRO PGM, shuffle or RMS (Random Music
Sensor) play modes. Repeat all the tracks or PLAY
only one track. MODE
=/+
PLAY
MODE
REPEAT/
During play, press PLAY MODE repeatedly
ENTER
until "SHUF" appears.
The tracks play in random order.
To repeat all the tracks
Press REPEAT/ENTER during play.
The " " indication appears.
To cancel shuffle play, press PLAY MODE
repeatedly until the play mode indication
disappears from the display.
Note
To cancel repeat play, press REPEAT/ENTER • During shuffle play, you cannot return to
previous tracks by pressing = .
again.
To repeat a single track
1 Press REPEAT/ENTER while the track you
want to repeat is playing.
The " " indication appears.
Playing tracks in the order
you want
(RMS Play)
You can program up to 22 tracks to play in
any order you choose.
2 Press PLAY MODE repeatedly until "1"
appears.
PLAY
MODE
REPEAT/
ENTER
To repeat another track, press = or + .
To cancel repeat play, press REPEAT/ENTER
again.
1
During play, press PLAY MODE
repeatedly until "RMS*" flashes.
Flashing
Playing only the tracks
you want
(INTRO PGM Play)
You can choose and play your favorite tracks *RMS = Random Music Sensor
by scanning through the beginning of each
2
track in a CD. Press = or + to choose a track.
The track number and the playing order
appear.
PLAY +
MODE
Track number Flashing
^
REPEAT/
ENTER
Playing order
1
During play, press PLAY MODE
3
repeatedly until "INTRO PGM" flashes. Press REPEAT/ENTER to program the
track.
Flashing
4
Repeat steps 2 and 3 to program the
remaining tracks.
5
Press ^ .
"RMS" stops flashing and the tracks you
2
Press ^ to start scanning .
have chosen play in the order you
The player plays about the first 15
specified.
seconds of each track and "INTRO PGM"
flashes faster.
If you press p, the program will be erased.
To prevent accidental erasure, set the
3
Press REPEAT/ENTER while the track RESUME switch to ON.
you want is playing. To skip the track,
press + or just wait for the next track.
To cancel RMS play, press PLAY MODE until
"RMS" disappears.
After you have gone through the CD,
"INTRO PGM" stops flashing and the tracks
To check the program
you have chosen play automatically.
During programming:
Press REPEAT/ENTER before step 5.
To finish programming before going through
During RMS play:
the whole CD, press ^. The selected tracks
Press PLAY MODE repeatedly until "RMS"
will be played.
flashes, then press REPEAT/ENTER.
Each time you press REPEAT/ENTER, the
If you press p, the program will be erased. To
track number and the playing order appear in
prevent accidental erasure, set the RESUME
the order you specified.
switch to ON.
Note
To cancel INTRO PGM play, press PLAY
• If you program another track after the 22nd
MODE repeatedly until the play mode
track, the first track programed is cleared and
indication disappears from the display. the new track is programed instead.
Using other functions
To minimize skipping (ESP 2 )
The ESP (Electronic Shock Protection)
function minimize skipping by using a buffer
memory that stores music data and plays it
back in the event of a shock.
The new ESP 2 (ESP Squared) system uses a
new DSP (Digital Signal Processor) which can
read and store music data more efficiently,
providing a level of continuous skip
protection not found in traditional buffer
memory units. This decreases the frequency
of sound skipping and the need to utilize the
buffer memory. Use this function when
listening in a car or while walking.*
2
* Although ESP provides excellent protection
against skipping, it will not prevent skipping
while jogging or running.
ESP
Press ESP.
The ESP indication appears.
To release the ESP function, press ESP again.
Notes
• Playing may stop when the player gets a strong
shock even with the ESP function on.
• You may hear a noise or sound skip when:
— listening to a dirty or scratched CD,
— listening to an audio test CD or,
— the player receives continuous shock.
• Sound may drop for a while if you press ESP
=/+
during play.
To enjoy more powerful bass sound
^
(Sound function)
You can enjoy a powerful bass-boosted sound.
SOUND
Press SOUND to select "BASS" or "GROOVE."
"GROOVE" is more effective.
Note
• If the sound is distorted when emphasizing
bass, turn down the volume.
To lock the buttons
You can lock your player against any
accidental operations.
HOLD
Press HOLD until appears in the
display and you cannot operate the player.
To unlock, press HOLD until
disappears from the display.
Continue to the reverse side m
