Disconnect the labeled wires

Be sure you have taken a photo of
your wires before disconnecting.
Disconnect only the wires that you
just labeled. Do not disconnect any
unlabeled wires.
If unlabeled wires disconnect, replace
immediately.
Note: You may need a screwdriver to
release wires from terminals.
*
*
EXAMPLE
G
C
R
W or W1
W2
*
Y or Y1
