Summary of Contents for DSC LC-151
- Page 1 LC-151 Dual-Tech Motion Sensor (Single PIR & Microwave) with adjustable Pet Immunity INSTALLATION INSTRUCTIONS & USER MANUAL P/N: 7131720 ver.B...
-
Page 2: Table Of Contents
General............................3 Features ............................ 3 Assembly description......................... 4 Detection Pattern........................5 Selecting mounting location....................... 7 Detector Installation........................8 Terminal Block Connections....................10 Wire Size Requirements....................10 Settings & Adjustments ......................11 Detection beam direction....................11 Detection beam range setting ..................11 Sensitivity Adjustment ...................... -
Page 3: General
The LC-151 is designed to protect large areas and can easily be installed on walls in order to provide a solid protection of the area while rejects interferences from birds and small animals due to the optional “PET MASK”... -
Page 4: Assembly Description
Assembly description The LC-151 is a robust yet small detector which includes a large LED indicator that can be easily observed from long distances to provide indication of intrusion. Using the supplied mounting bracket, the LC-151 can be easily mounted to walls using the provided mounting screws. For installations requiring the detection beam to be adjusted horizontally or vertically to obtain the desired field of protection use the LC-B1-15X Outdoor Mounting Bracket pictured below. -
Page 5: Detection Pattern
Detection Pattern The LC-151 has a 90° top view PIR and MW detection pattern with over 15m (49 ft) detection distance (when installed at 2.4m (7.8 ft) above the ground surface). Standard Lens... - Page 6 LC-L1-15X Corridor Lens (sold separately) The LC-151 can differentiate between pets and human bodies and alert accordingly by utilizing microwave movement detection combined with a PIR detection beam. An intrusion is defined by the PIR detection beam being crossed and a microwave detection occurring, causing an alarm.
-
Page 7: Selecting Mounting Location
The LC-151 performs best when provided with a constant and stable environment. x In order to ensure suitable operation of the LC-151, the type of ground should be one of the following: Asphalt concrete, Cement, Soil, Clay, Gravel or Grass (mown). -
Page 8: Detector Installation
Detector Installation Important! Prior to installation, read both “Operation” and “Selecting the mounting location” sections carefully. 1. Install the detector in such manner that the intruder is 2. The detector is to be installed at height of 1.8 to 2.4 most likely to cross the detection area from side to side. - Page 9 7. Release the detector body from the metal bracket by 8. Attach the rear bracket to the wall using mounting pulling the detector up and out. screws. 9. Insert wires through provided access hole and wiring 10. Attach the sealing sponge pad to the wire opening channels.
-
Page 10: Terminal Block Connections
Terminal Block Connections Terminal 1 - Marked “+” (+12V) - Connect to a positive Voltage of 9.6 -16Vdc source (usually from the control panel) Terminal 2 - Marked “-” (GND) - Connect to the ground of the control panel. Terminals 3 & 4 - Marked “TAMPER” - If a Tamper function is required connect these Terminals to a normally closed 24-Hour Tamper Zone on the control panel. -
Page 11: Settings & Adjustments
Settings & Adjustments 8.1 Detection beam direction The LC-151 detection beam direction is fixed. As a result, it is recommended to face the intrusion area with the detector. 8.2 Detection beam range setting The detection range may be set by tilting the detector while installed using the LC-B1-15X Outdoor Mounting Bracket. -
Page 12: Indications Setting
If the detector is used in a space which contains several bushes and a swimming pool the environmental conditions should be considered a "Noisy Area" 8.4 Indications setting The LC-151 has 3 LEDs that each points at different indication: 1. Green LED indicates PIR detection. 2. Yellow LED indicates Microwave detection. - Page 13 When the LED jumper is in the "ON" position the LEDs will be active. When the LED jumper is in the "OFF" position, the LEDs will not activate. Detection LEDs LEDs Control jumper (Factory setting: ON) x Place the top cover to the base and close it using the bottom screw. x Place the top visor in place.
-
Page 14: Operation
Operation Note! Connect the LC-151 to a positive Voltage output of 9.6 -16Vdc source. Use only a listed power limited source. The detector shall be provided with minimum of 4 hours of standby power from either a listed compatible control unit or power supply. -
Page 15: Specifications
12 Specifications Detection Method PIR AND MW Microwave Frequency X-band (9.9GHz / 10.525GHz / 10.687GHz) Power Input 9.6 to 16Vdc Current Draw Active: 24mA (±5%); Standby: 21mA (±5%) Temp Compensation Dual slope temperature compensation Alarm Period 2 sec (±0.5sec) Form C (NC, NO, Common) Alarm Outputs 28Vdc 0.1 A with 10 Ohm Two Switches...
